Fieldbus Controller 750-837, /02x-000, 750-838, /02x-000 • 111

Technical Data

Technical data





Max. number of I/O modules

64







Fieldbus





- Input process image

max. 512 bytes

- Output process image

max. 512 bytes

- Input variables



max. 512 bytes

- Output variables



max. 512 bytes







Configuration



via PC or PLC







Data memory

750-837, -838:

- 64 kbytes

750-837/020-000, 750-838/020-000:

- 192 kbytes

750-837/020-000, 750-838/020-000:

- 832 kbytes







Program memory

750-837, -838:

- 128 kbytes

750-837/020-000, 750-838/020-000:

- 256 kbytes

750-837/020-000, 750-838/020-000:

- 640 kbytes





Non-volatile memory

8 kbytes (retain)







Cycle time



< 3ms for 1,000 statements/256 dig. I/Os







No. of PDOs



32 Tx / 32 Rx







No. of SDOs



2 Server SDO/ 16 Client SDO





Communication profile

DS-301 V4.01







Device profile



DS-401 V2.0, marginal check, edge-triggered





PDOs, programmable error response, DSP 405





NMT master can be programmed using function





blocks







COB ID Distribution



SDO, Standard





Node ID Distribution

DIP switches





Other CANopen Features

NMT Slave, NMT Master, Minimum Boot-up,





Variables PDO Mapping, Emergency Message,





Life Guarding/ Heartbeat, Configuration of virtual





modules







Voltage supply



DC 24 V (-25 %...+ 30 %)







Input current max



500 mA at 24 V

Efficiency of the power supply

87 %





Internal power consumption

350 mA at 5 V





Total current for I/O modules

1650 mA at 5 V





Voltage via power jumper contacts

DC 24 V (-25 %...+ 30 %)





Current via power jumper contacts max

DC 10 A

Dimensions (mm) W x H x L

51 x 65* x 100 (*from top edge of mounting rail)







Weight



ca. 195 g







WAGO-I/O-SYSTEM 750

CANopen

112 • I/O Modules

4 I/O Modules

4.1 General

All listed bus modules, in the review below, are available for modular applications with the WAGO-I/O-SYSTEM 750.

For detailed information on the I/O modules and the module variations, please refer to the manuals for the I/O modules.

You will find these manuals on CD ROM „ELECTRONICC Tools and Docs“ (Item-no.: 0888-0412-0001-0101) or on the web pages:

www.wago.com / Support / Tech. Documentation / WAGO-I/O-SYSTEM 750 / Manuals / I/O Modules.

More Information

Current information on the modular WAGO-I/O-SYSTEM is available in the Internet under:

www.wago.com

4.2 Digital Input Modules

DI DC 5 V

750-414 4 Channel, DC 5 V, 0.2 ms, 2- to 3-conductor connection, high-side switching

DI DC 24 V

750-400 2 Channel, DC 24 V, 3.0 ms, 2- to 4-conductor connection; high-side switching

750-401 2 Channel, DC 24 V, 0.2 ms, 2- to 4-conductor connection; high-side switching

750-410 2 Channel, DC 24 V, 3.0 ms, 2- to 4-conductor connection; high-side switching

750-411 2 Channel, DC 24 V, 0.2 ms, 2- to 4-conductor connection; high-side switching

750-418 2 Channel, DC 24 V, 3.0 ms, 2- to 3-conductor connection; high-side switching; diagnostic

750-419 2 Channel, DC 24 V, 3.0 ms, 2- to 3-conductor connection; high-side switching; diagnostic

750-421 2 Channel, DC 24 V, 3.0 ms, 2- to 3-conductor connection; high-side switching; diagnostic

750-402 4 Channel, DC 24 V, 3.0 ms, 2- to 3-conductor connection; high-side switching

750-432 4 Channel, DC 24 V, 3.0 ms, 2-conductor connection; high-side switching

750-403 4 Channel, DC 24 V, 0.2 ms, 2- to 3-conductor connection; high-side switching

WAGO-I/O-SYSTEM 750

CANopen

I/O Modules • 113

750-433 4 Channel, DC 24 V, 0.2 ms, 2-conductor connection; high-side switching

750-422 4 Channel, DC 24 V, 2- to 3-conductor connection; high-side switching; 10 ms pulse extension

750-408 4 Channel, DC 24 V, 3.0 ms, 2- to 3-conductor connection; low-side switching

750-409 4 Channel, DC 24 V, 0.2 ms, 2- to 3-conductor connection; low-side switching

750-430 8 Channel, DC 24 V, 3.0 ms, 1-conductor connection; high-side switching

750-431 8 Channel, DC 24 V, 0.2 ms, 1-conductor connection; high-side switching

DI AC/DC 24 V

750-415 4 Channel, AC/DC 24 V, 2-conductor connection

750-423 4 Channel, AC/DC 24 V, 2- to 3-conductor connection; with power jumper contacts

DI AC/DC 42 V

750-428 4 Channel, AC/DC 42 V, 2-conductor connection

DI DC 48 V

750-412 2 Channel, DC 48 V, 3.0ms, 2- to 4-conductor connection; high-side switching

DI DC 110 V

750-427 2 Channel, DC 110 V, Configurable high-side or low-side switching

DI AC 120 V

750-406 2 Channel, AC 120 V, 2- to 4-conductor connection; high-side switching

DI AC 230 V

750-405 2 Channel, AC 230 V, 2- to 4-conductor connection; high-side switching

NAMUR

750-425 2 Channel, NAMUR, Proximity switch acc. to DIN EN 50227

750-435 1 Channel, NAMUR EEx i, Proximity switch acc. to DIN EN 50227

750-438 2 Channel, NAMUR EEx i, Proximity switch acc. to DIN EN 50227

Intruder Detection

750-424 2 Channel, DC 24 V, Intruder Detection

WAGO-I/O-SYSTEM 750

CANopen

114 • I/O Modules

4.3 Digital Output Modules

DO DC 5 V

750-519 4 Channel, DC 5 V, 20mA, short-circuit-protected; high-side switching

DO DC 24 V

750-501 2 Channel, DC 24 V, 0.5 A, short-circuit-protected; high-side switching

750-502 2 Channel, DC 24 V, 2.0 A, short-circuit-protected; high-side switching

750-506 2 Channel, DC 24 V, 0.5 A, short-circuit-protected; high-side switching; with diagnostics

750-507 2 Channel, DC 24 V, 2.0 A, short-circuit-protected; high-side switching; with diagnostics

750-535 2 Channel, DC 24 V, EEx i, short-circuit-protected; PNP-positive switching

750-504 4 Channel, DC 24 V, 0.5 A, short-circuit-protected; high-side switching

750-531 4 Channel, DC 24 V, 0.5 A, short-circuit-protected; high-side switching

750-516 4 Channel, DC 24 V, 0.5 A, short-circuit-protected; low-side switching

750-530 8 Channel, DC 24 V, 0.5 A, short-circuit-protected; high-side switching

DO AC/DC 230 V

750-509 2 Channel Solid State Relay, AC/DC 230 V, 300 mA

750-522 2 Channel Solid State Relay, AC/DC 230 V, 500 mA, 3 A (< 30 s)

DO Relay

750-514 2 Channel, AC 125 V , AC 0.5 A , DC 30 V, DC 1 A, isolated outputs, 2 changeover contacts

750-517 2 Channel, AC 230 V, 1 A, isolated outputs, 2 changeover contacts

750-512 2 Channel, AC 230 V, DC 30 V, AC/DC 2 A, non-floating, 2 make contacts

750-513 2 Channel, AC 230 V, DC 30 V, AC/DC 2 A, isolated outputs, 2 make contacts

750-523 1 Channel, AC 230 V, AC 16 A, isolated output, 1 make contact, bistable, manual operation

WAGO-I/O-SYSTEM 750

CANopen

I/O Modules • 115

4.4 Analog Intput Modules

AI 0 - 20 mA

750-452 2 Channel, 0 - 20 mA, Differential Inputs

750-453 4 Channel, 0 - 20 mA, single-ended (S.E.)

750-465 2 Channel, 0 - 20 mA, single-ended (S.E.)

750-472 2-channel, 0 - 20 mA, 16 Bit, single-ended (S.E.)

750-480 2-channel, 0 - 20 mA ,Differential Inputs

AI 4 - 20 mA

750-454 2 Channel, 4 - 20 mA,Differential Inputs

750-455 4 Channel, 4 - 20 mA, single ended (S.E.)

750-474 2 Channel, 4 - 20 mA, 16 Bit, single-ended (S.E.)

750-466 2 Channel, 4 - 20 mA, single ended (S.E.)

750-485 2 Channel, 4 - 20 mA, EEx i, single ended (S.E.)

750-492 2 Channel, 4 - 20 mA, Isolated Differential Inputs

AI 0 - 1 A

750-475 2-channel, 0 - 1 A AC/DC ,Differential Inputs

AI 0 - 10 V

750-459 4 Channel, DC 0 - 10 V, single-ended (S.E.)

750-467 2 Channel, DC 0 - 10 V, single-ended (S.E.)

750-468 4 Channel, DC 0 - 10 V, single-ended (S.E.)

750-477 2 Channel, AC/DC 0 - 10 V,Differential Inputs

750-478 2 Channel, DC 0 - 10 V, single-ended (S.E.)

AI DC ± 10 V

750-456 2 Channel, DC ± 10 V,Differential Inputs

750-457 4 Channel, DC ± 10 V, single-ended (S.E.)

750-479 2 Channel, DC ± 10 V,Differential Measurement Input

750-476 2 Channel, DC ± 10 V, single-ended (S.E.)

AI DC 0 - 30 V

750-483 2 Channel, DC 0 -30 V,Differential Measurement Input

AI ...

750-461 2 Channel, Resistance Sensors, PT100 / RTD

750-481/ 2 Channel, Resistance Sensors, PT100 / RTD, EEx i 003-000

750-460 4 Channel, Resistance Sensors, PT100 / RTD

750-469 2 Channel, thermocouples with diagnostics Sensor types: J, K, B, E, N, R, S, T, U, L

750-491 1 Channel for Resistor Bridges (Strain Gauge)

WAGO-I/O-SYSTEM 750

CANopen
