126 • CANopen

Network Communication

5.3.1 Communication Objects

5.3.1.1 Process Data Object - PDO

PDOs contain real time data with high priority identifiers. The data telegrams consist of a maximum of 8 bytes and can be interchanged among the individual sub-assemblies, as required. This data exchange can be optionally event controlled or performed in a synchronized manner. The event controlled mode allows the bus load to be drastically reduced permitting a high communication capacity at a low Baud rate. However, the various modes can also be processed as a mix (see chapter 5.3.4.2.20 "Object 0x1400– 0x141F, Receive PDO Communication Parameter")

5.3.1.1.1 PDO Protocol

This protocol is used to transmit data from/to the bus coupler without protocol overhead. PDOs consist only of the CAN identifier and the data field. No further protocol information is contained in a PDO. The contents of the data are defined by the mapping parameters and the transmission type by the communication parameters.

A differentiation is made between RxPDO (receipt PDO) and TxPDO (transmit PDO).

Receive Process Data Object (RxPDO)

Client



Server









COB-ID = yy















0

8















Data

































































Fig. 5-5: RxPDO

g012403x

Transmit Process Data Object (TxPDO)

Client



Server





RTR-Frame, COB ID = xx





COB-ID = xx



0

8





Data

Fig. 5-6:

TxPDO

g012404x

WAGO-I/O-SYSTEM 750

CANopen

CANopen • 127

Network Communication

5.3.1.2 Service Data Object - SDO

The SDOs can be used to read and/or write entries in the object directory. In this manner, a CANopen subscriber can be fully configured. The default SDO is pre-assigned with a low priority identifier. The transmitted data has to be distributed to several messages if it exceeds 4 bytes.

5.3.1.2.1 SDO Protocol

A specific protocol overhead that is indispensable for transmission and contains the command specifier, the index and the sub-index of the entry to be read/written.

5.3.1.2.1.1General Design

Receive Service Data Object (RxSDO)

Client











Server









COB-ID = 1536 + Module ID



























0

1

2

3

4

8





































Command

Index

Index

Sub



Data













specifier

Low Byte

High Byte

Index













































































Transmit Service Data Object (TxSDO)

Client











Server









COB-ID = 1408 + Module ID



























0

1

2

3

4

8





































Command

Index

Index

Sub



Data













specifier

Low Byte

High Byte

Index







































































Fig. 5-7: SDO Protocol















g012405x

5.3.1.2.1.2Download SDO Protocol

This protocol is used to write data from the master into the bus coupler.

5.3.1.2.1.2.1Initiate SDO Download

This protocol is used to initiate the data transmission from the master to the bus coupler. When transmitting data of max. 4 bytes, these are also transmitted within the protocol.

WAGO-I/O-SYSTEM 750

CANopen

128 • CANopen

Network Communication



Initiate SDO Download

Client

Server





0







1

4

8























request



























indication





.7 .6 .5

.4

.3 .2

.1

.0









































ccs = 1

x

n

e

s



m



Data











































































































































Initiate SDO Download

Client

Server





0









1

4

8

























confirm



























response



.7 .6 .5

.4

.3

.2

.1

.0







































scs = 3

x

x

x

e

s



m



Data





































































































































Fig. 5-8:

Initiate SDO

g012406x

ccs:

client command specifier

1: initiate download request

scs:

server command specifier

3: initiate download response

n:

only valid if e = 1

If n is valid, it displays the number of bytes which



and s = 1, otherwise 0.

do not contain any data. Example:





3 data bytes, e = 1 and s = 1, n = 4 - 3 = 1

e:

transfer type

0: normal transfer, number of the bytes to be writ-





ten >= 5 byte





1: expedited transfer, number of the bytes to be





written < 5 byte

s:

size indicator

0: data set size is not displayed





1: data set size is displayed





s is always 1

m:

multiplexor

Index and Sub-Index of object directory





Index, Low Byte : Byte #1





Index, High Byte: Byte #2





Sub-Index: Byte #3

d:

data

e = 0, s = 0: d is reserved for further use of CiA





e = 0, s = 1: d contains the number of bytes for





download





Byte 4 contains the LSB and Byte 7 contains the





MSB.





e = 1: d contains the data

X:



Not used, always 0

reserved:



Reserved for further use of CiA











WAGO-I/O-SYSTEM 750





CANopen

CANopen • 129

Network Communication

5.3.1.2.1.2.2Download SDO Segment

This protocol is used to transmit more than 4 data, i. e. this follows after fully processing the „Initiate SDO Download Protocol" which initiates the data transmissions.



Download SDO Segment

Client

Server



0







1

8







request























indication



.7 .6 .5

.4

.3

.2

.1

.0



























ccs = 0

t



n



c



Segment data



























































































Download SDO Segment

Client

Server





0





1

8







confirm



















response



.7 .6 .5

.4

.3

.2 .1 .0































scs = 1

t



x



reserved





















































































Fig. 5-9: Download SDO Segment

g012409x

ccs:

client command specifier

0: download segment request

scs:

server command specifier

1: download segment response

seg-data

Contains the data to be

The meaning of the data is determined by the



transmitted.

application.

n:



Displays the number of bytes not containing any





data. n is 0 if no segment size is displayed.

c:Indicates whether or not a download is necessary for further data.

0:There is more data to be downloaded.

1:There is no more data to be downloaded.

t:

Toggle Bit

This bit must be able to toggle for each segment





for which a download is made. The first segment





zeroes the toggle bit. The toggle bit is identical





both for the enquiry and the reply message.

X:



Not used, always 0

reserved:



Reserved for further use of CiA

WAGO-I/O-SYSTEM 750

CANopen

130 • CANopen

Network Communication

5.3.1.2.1.3Upload SDO Protocol

This protocol is used to read data out of the bus coupler.

5.3.1.2.1.3.1Initiate SDO Upload

The data transmission from the bus coupler to the master is initiated with this protocol. When transmitting data of max. 4 bytes, these are also transmitted within the protocol.



Initiate SDO Upload

Client

Server





0



1

4

8



















request























indication





.7 .6 .5

.4 .3 .2

.1 .0









































ccs = 2

x





m



reserved



































































































































Initiate SDO Upload

Client

Server





0







1

4

8























confirm



























response





.7 .6 .5

.4

.3 .2

.1

.0









































scs = 2

x

n

e

s



m



Data









































































































































Fig. 5-10: Initiate SDO Upload

g012410x

ccs:

Client command specifier

2: initiate upload request

scs:

Server command specifier

2: initiate upload response

n:is only valid if e = 1 and s = If n is valid, it displays the number of bytes in d 1, otherwise 0. which do not contain any data. The bytes [8-n, 7]





do not contain segment data.

e:

transfer type

0: normal transfer, number of bytes to be written





>= 5 bytes





1: expedited transfer, number of bytes to be





written < 5 bytes

s:

size indicator

0: the number of bytes to be transmitted is not





displayed





1: the number of bytes to be transmitted is dis-





played (depending on the number of bytes)

m:

multiplexor

Index and sub-index of the object directory:





Index, Low Byte : Byte #1





Index, High Byte: Byte #2





Sub-Index: Byte #3











WAGO-I/O-SYSTEM 750





CANopen
