156 • CANopen

Network Communication

5.3.4.2.20Object 0x1400– 0x141F, Receive PDO Communication Parameter



Idx





S-Idx





Name





Type



Attribute



Default Value



0x1400 to



0



Max. supported





Unsigned8



RO

2



0x141F











Entries





















1



COB-ID





Unsigned32



RW



Idx 0x1400 0x200+Module-ID





























Idx 0x1401 0x300+Module-ID





























Idx 0x1402 0x400+Module-ID





























Idx 0x1403 0x500+Module-ID





























Idx 0x1404-141F 0x80000000







2



Transmission type





Unsigned8



RW

255

This object is used to set the communication parameters of the RxPDOs. 32 RxPDOs are supported. The default COB IDs of the first four PDOs are preassigned according to the DS301 standard. All further PDOs are deactivated. If not all default PDOs are used (i.e. a smaller number of modules is connected), also the default PDOs not used are deactivated.

Design COB-ID:

Bit31

Bit 30

Bit29

Bit11

Bit10

Bit0













0/1

0/1

reserved (always 0)



COB-ID



valid/invalid

RTR allowed / not











allowed









If a new COB ID is to be entered, bit 31 must be set to 1 first, because the DS301 standard does not permit to change a valid COB ID (Bit31=0).

A mode can be defined for each PDO for the purpose of data transmission (transmission type in the Index Communication Parameter). As standard, digital and analog inputs are transmitted as ´Change of Value´(COV). The type of transmission depending of the set transmission type is explained in the following table.

Transmis-

PDO transmission











sion type



















cyclic

acyclic



synchro-

asyn-

RTR

TxPDO

RxPDO









nous

chro-

only

(Inputs)

(outputs)











nous







0



X



X





if COV is transmitted

Set outputs after each















with each SYNC

SYNC as requested by the

















last PDO received

1 – 240

X





X





Transmission with

Set outputs after each















each x SYNC

SYNC as requested by the















(x = 1 to 240)

last PDO received

241 – 251

- reserved

-













252







X



X

Data is read-in again

Not supported















with a SYNC, but not

















sent,

















request via RTR



253









X

X

Request via RTR

COV

254









X



COV 1

COV

255









X



COV 1

COV

1 the data is transmitted at the interval of the set inhibit time

WAGO-I/O-SYSTEM 750

CANopen

CANopen • 157

Network Communication

5.3.4.2.21Object 0x1600– 0x161F, Receive PDO Mapping Parameter



Idx





S-Idx





Name



Type











Default Value





0x1600 to



0



Number of mapped



Unsigned8



RW



-





0x161F











Objects









RW

















1 to 8



1. Object to 8. Object



Unsigned32





-



This object is used to define the data, which is to be transmitted by means of the PDO.

Sub-index 0 contains the number of objects valid for the PDO.

Design 1. to 8. Object:

Bit31

Bit16 Bit 15

Bit8 Bit7

Bit0













Index



Sub-Index



Size















Index:

Index of the object to be transmitted

Sub-Index:

Sub-index of the object to be transmitted

Size:

Object size in bits



Due to the fact that max. 8 bytes can be transmitted in a



PDO, the sum of the valid object lengths must not exceed

64(8Byte*8Bit)

5.3.4.2.22Object 0x1800– 0x181F, Transmit PDO Communication Parameter



Idx



S-Idx



Name



Type







Default Value





0x1800 to



0



Max. supported



Unsigned8



RO



5





0x181F







Entries







RW













1



COB-ID



Unsigned32





Idx 0x1800 0x180+Module-ID

























Idx 0x1801 0x280+Module-ID

























Idx 0x1802 0x380+Module-ID

























Idx 0x1803 0x480h+Module-ID





















RW



Idx 0x1804-181F 0x80000000









2



Transmission type



Unsigned8





255









3



Inhibit Time



Unsigned16



RW



Idx 0x1800 0





















RW



Idx 0x1801 – 181F 100









4



Reserved



Unsigned8





0









5



Event Timer



Unsigned16



RW



0



This object is used to set the communication parameters of the TxPDOs. 32 TxPDOs are supported. The default COB IDs of the first four PDOs are preassigned according to the DS301 standard. All other PDOs are de-activated. If not all default PDOs are used (i.e. a smaller number of modules is connected), also the default PDOs not used are de-activated.

Inhibit Time shows the min. time between two consecutive PDOs having the same COB ID. One time unit is 100us. The transmitted value is internally rounded to the next smaller milli-second.

WAGO-I/O-SYSTEM 750

CANopen

158 • CANopen

Network Communication

If a new value is to be entered, the COB ID has to be set invalid (Bit 31 = 1), because the DS301 standard does not permit to enter a new time when the COB ID (Bit31=0) is valid.

Example:

Min. time interval between two PDOs having the same COB



ID: 30ms.



Sub-index 3 = 300 = 0x12C

The Event Timer defines the time after the elapse of which a PDO is sent, even if no change of the PDO data has occurred. Enter the time in milliseconds. The timer is re-started whenever an event occurs (change to the PDO data).

If the time is shorter than the inhibit time, a new event is generated once the inhibit time has elapsed!

Attention

The event timer can only be used for the transmission types 254/255.

Attention

An object entry can only be mapped in a max. of 3 different PDOs.

5.3.4.2.23Object 0x1A00 – 0x1A1F, Transmit PDO Mapping Parameter

Idx

S-Idx

Name

Type

Attribute

Default Value

0x1A00 to

0

Number of mapped

Unsigned8

RW

-

0x1A1F



objects









1 to 8

1.Object to 8.Object

Unsigned32

RW

-

This object is used to define the data, which is transmitted using the PDO.

Sub-index 0 contains the number of objects valid for the PDO.

Design 1. to 8. Object:

Bit31

Bit16 Bit 15

Bit8 Bit7

Bit0













Index



Sub-Index



Size















Index:

Index of the object to be transmitted

Sub-Index:

Sub-index of the object to be transmitted

Size:

Size of the object in bits



Due to the fact that max. 8 bytes in a PDO can be transmit-



ted, the total of valid object lengths must not exceed 64



(8Byte*8Bit)

WAGO-I/O-SYSTEM 750

CANopen

CANopen • 159

Network Communication

5.3.4.3 Manufacturer Specific Profile Area

The non-standard device profile-specific I/O functionality of special modules and other modules as well as special functions (i.e. spacer module configuration,...) are imaged in the ‘Manufacturer Specific Area’ profile. The objects defined there provide data word widths of a modularity from 1 to 8 bytes. The indexes 0x2000 (digital inputs), 0x2100 (digital outputs), 0x2400 (2 byte special module inputs) and 0x2500 (2 byte special module outputs) are mirror imaged by the corresponding indexes of the device profile DS 401 (0x6000, 0x6200, 0x6401, 0x6411). This means for instance: object 0x2000 and object 0x6000 refer to the same memory places in the process image.

The following table shows all objects of the manufacturer profile supported by the bus coupler.

Idx

Name

Type

Meaning

See on









page

0x2000

Digital inputs

Array

Data of digital input modules

160





Unsigned8





0x2100

Digital outputs

Array

Data of digital output modules

160





Unsigned8





0x2200

1 byte special modules, inputs

Array

Data of 1 byte special input modules

160





Unsigned8





0x2300

1 byte special modules, outputs

Array

Data of 1 byte special output modules

160





Unsigned8





0x2400

2 byte special modules, inputs

Array

Data of 2 byte special input modules

160





Un-









signed16





0x2500

2 byte special modules, outputs

Array

Data of 2 byte special output modules

160





Un-









signed16





0x2600

3 byte special modules, inputs

Record

Data of 3 byte special input modules

160

0x2700

3 byte special modules, outputs

Record

Data of 3 byte special output modules

161

0x2800

4 byte special modules, inputs

Record

Data of 4 byte special input modules

161

0x2900

4 byte special modules, outputs

Record

Data of 4 byte special output modules

161

0x3000

5 byte special modules, inputs

Record

Data of 5 byte special input modules

161

0x3100

5 byte special modules, outputs

Record

Data of 5 byte special output modules

161

0x3200

6 byte special modules, inputs

Record

Data of 6 byte special input modules

161

0x3300

6 byte special modules, outputs

Record

Data of 6 byte special output modules

161

0x3400

7 byte special modules, inputs

Record

Data of 7 byte special input modules

162

0x3500

7 byte special modules, outputs

Record

Data of 7 byte special output modules

162

0x3600

8 byte special modules, inputs

Record

Data of 8 byte special input modules

162

0x3700

8 byte special modules, outputs

Record

Data of 8 byte special output modules

163

0x4200-

Gateway-Module-Input

Record

Input data of Gateway modules

160

0x4202









0x4300-

Gateway-Module-Output

Record

Output data of Gateway modules

163

0x4302









0x4500

Spacer module configuration

Record

Configuration of virtual modules

163

0x5000

Input PA

Record

Reading of the input process image

168

0x5001

Output PA

Record

Writing the output process image

168

0x5200

Controller Configuration Object

Record

Deactivate PDO processing, blink code

168







display and I/O module diagnostics



0x5201

Diagnostic Configuration Object

Array of

Diagnostic behavior of the I/O modules

169





Byte





WAGO-I/O-SYSTEM 750

CANopen

160 • CANopen

Network Communication

5.3.4.3.1 Object 0x2000, Digital Inputs



Idx





S-Idx





Name





Type





Attribute





Default Value





Meaning





0x2000



0



8-Bit digital input block



Unsigned8



RO



-





Number of digital 8 bit input blocks









1



1. input block





Unsigned8



RO



-





1. digital input block









....



....



....



....



....



....









32



32. input block





Unsigned8



RO



-





32. digital input block



5.3.4.3.2 Object 0x2100, Digital Outputs



















Idx

S-Idx

Name

Type

Attribute

Default Value

Meaning

0x2100

0

8-Bit digital output block

Unsigned8

RO

-

Number of digital 8 bit output blocks



1

1. output block

Unsigned8

RW

0

1. digital output block



....

....

....

....

....

....



32

32. output block

Unsigned8

RW

0

32. digital output block

5.3.4.3.3 Object 0x2200, 1 Byte Special Modules, Inputs



Idx

S-Idx

Name

Type

Attribute

Default Value

Meaning

0x2200

0

Special 1 byte input

Unsigned8

RO

-

Number of the 1 byte special channels



1

1. special input

Unsigned8

RO

-

1. Input channel



....

....

....

....

....

....



254

254. special input

Unsigned8

RO

-

254. Input channel

5.3.4.3.4 Object 0x2300, 1 Byte Special Modules, Outputs



Idx

S-Idx

Name

Type

Attribute

Default Value

Meaning

0x2300

0

special 1 byte output

Unsigned8

RO

-

Number of the 1 byte special channels



1

1. special output

Unsigned8

RW

0

1. Output channel



....

....

....

....

....

....



254

254. special output

Unsigned8

RW

0

254. Output channel

5.3.4.3.5 Object 0x2400, 2 Byte Special Modules, Inputs



Idx

S-Idx

Name

Type

Attribute

Default Value

Meaning

0x2400

0

special 2 byte input

Unsigned8

RO

-

Number of the 2 byte special channels



1

1. special input

Unsigned16

RO

-

1. Input channel



....

....

....

....

....

....



254

254. special input

Unsigned16

RO

-

254. Input channel

5.3.4.3.6 Object 0x2500, 2 Byte Special Modules, Outputs



Idx

S-Idx

Name

Type

Attribute

Default Value

Meaning

0x2500

0

special 2 byte output

Unsigned8

RO

-

Number of the 2 byte special channels



1

1. special output

Unsigned16

RW

0

1. Output channel



....

....

....

....

....

....



254

254. special output

Unsigned16

RW

0

254. Output channel

5.3.4.3.7 Object 0x2600, 3 Byte Special Modules, Inputs



Idx

S-Idx

Name

Type

Attribute

Default Value

Meaning

0x2600

0

special 3 byte input

Unsigned8

RO

-

Number of the 3 byte special channels



1

1. special input

Unsigned24

RO

-

1. Input channel



....

....

....

....

....

....



170

170. special input

Unsigned24

RO

-

170. Input channel

WAGO-I/O-SYSTEM 750

CANopen
