750-638

The above Counter Modules have a total of 6 bytes of user data in both the Input and Output Process Image (4 bytes of counter data and 2 bytes of control/status). The two counter values are supplied as 16 bits. The following tables illustrate the Input and Output Process Image, which has a total of 6 bytes mapped into each image.

Input Process Image

These modules present themselves with 2x3 bytes, so that the object 0x2600 for 3 byte Special Modules, Inputs is used. Therefore for each channel one Subindex is occupied.

Output Process Image

These modules present themselves with 2x3 bytes, so that the object 0x2700 for 3 byte Special Modules, Outputs is used. Therefore for each channel one Subindex is occupied.

Pulse Width Modules

750-511, (and all variations)

The above Pulse Width modules have a total of 6 bytes of user data in both the Input and Output Process Image (4 bytes of channel data and 2 bytes of control/status). The two channel values are supplied as 16 bits. Each channel has its own control/status byte. The following table illustrates the Input and Output Process Image, which has a total of 6 bytes mapped into each image.

WAGO-I/O-SYSTEM 750

CANopen

62• Fieldbus Controller 750-837, /02x-000, 750-838, /02x-000 Process Image

Input and Output Process Image

These modules present themselves with 2x3 bytes, so that the object 0x2600 for 3 byte Special Modules, Inputs and the object 0x2700 for 3 byte Special Modules, Outputs are used. Therefore for each channel one Subindex is occupied.

Serial Interface Modules with alternative Data Format

750-650, (and the variations /000-002, -004, -006, -009, -010, -011, -012, -013)

750-651, (and the variations /000-002, -003) 750-653, (and the variations /000-002, -007)

Note:

With the freely parametrizable variations /003 000 of the serial interface modules, the desired operation mode can be set. Dependent on it, the process image of these modules is then the same, as from the appropriate variation.

The above Serial Interface Modules with alternative data format have a total of 4 bytes of user data in both the Input and Output Process Image (3 bytes of serial data and 1 byte of control/status). The following table illustrates the Input and Output Process Image, which have a total of 4 bytes mapped into each image.

Input and Output Process Image

These modules present themselves with 2x2 bytes, so that the object 0x6401 (also 0x2400 possible) for 2 byte Special Modules, Inputs and the object 0x6411 (also 0x2500 possible) for 2 byte Special Modules, Outputs are used. Therefore for each module one Subindex is occupied.

WAGO-I/O-SYSTEM 750

CANopen

Serial Interface Modules with Standard Data Format

750-650/000-001, -014, -015, -016 750-651/000-001 750-653/000-001, -006

The above Serial Interface Modules with Standard Data Format have a total of 6 bytes of user data in both the Input and Output Process Image (5 bytes of serial data and 1 byte of control/status). The following table illustrates the Input and Output Process Image, which have a total of 6 bytes mapped into each image.

Input and Output Process Image

These modules present themselves with 1x6 bytes, so that the object 0x3200 for 6 byte Special Modules, Inputs and the object 0x3300 for 6 byte Special Modules, Outputs are used. Therefore for each module one Subindex is occupied.

Data Exchange Module

750-654, (and the variation /000-001)

The Data Exchange modules have a total of 4 bytes of user data in both the Input and Output Process Image. The following tables illustrate the Input and Output Process Image, which has a total of 4 bytes mapped into each image.

Input and Output Process Image

These modules present themselves with 2x2 bytes, so that the object 0x6401 (also 0x2400 possible) for 2 byte Special Modules, Inputs and the object 0x6411 (also 0x2500 possible) for 2 byte Special Modules, Outputs are used. Therefore for each module two Subindices are occupied

WAGO-I/O-SYSTEM 750

CANopen

64• Fieldbus Controller 750-837, /02x-000, 750-838, /02x-000 Process Image

SSI Transmitter Interface Modules with alternative Data Format

750-630, (and the variations /000-001, -002, -006, -008, -009, -011, -012, -013)

Note:

With the freely parametrizable variations /003 000 of the SSI Transmitter interface modules, the desired operation mode can be set. Dependent on it, the process image of these modules is then the same, as from the appropriate variation.

The above SSI Transmitter Interface modules with alternative data format have a total of 4 bytes of user data in the Input Process Image. The following table illustrates the Input Process Image, which has a total of 4 bytes mapped into the image.

Input Process Image

These modules present themselves with 2x2 bytes, so that the object 0x6401 (also 0x2400 possible) for 2 byte Special Modules, Inputs is used. Therefore for each module two Subindices are occupied

SSI Transmitter Interface modules with Standard Data Format

750-630/000-004, -005, -007

The above SSI Transmitter Interface modules with Standard Data Format have a total of 5 bytes of user data in the Input Process Image (4 bytes of user data and 1 byte of status). The following table illustrates the Input Process Image, which has a total of 6 bytes mapped into the image.

Input Process Image

WAGO-I/O-SYSTEM 750

CANopen

These modules present themselves with 1x6 bytes, so that the object 0x3200 for 6 byte Special Modules, Inputs is used. Therefore for each module one Subindex is occupied

Incremental Encor Interface Modules

750-631

The above Incremental Encor Interface modules have 5 bytes of input data and 3 bytes of output data. The following tables illustrate the Input and Output Process Image, which have 6 bytes mapped into each image.

Input Process Image

These modules present themselves with 1x6 bytes, so that the object 0x3200 for 6 byte Special Modules, Inputs is used. Therefore for each module one Subindex is occupied

Output Process Image

These modules present themselves with 1x6 bytes, so that the object 0x3300 for 6 byte Special Modules, Outputs is used. Therefore for each module one Subindex is occupied
