MOTOROLA

SEMICONDUCTOR TECHNICAL DATA

Quad Analog Switch/

Multiplexer/Demultiplexer

High±Performance Silicon±Gate CMOS

The MC54/74HC4016 utilizes silicon±gate CMOS technology to achieve fast propagation delays, low ON resistances, and low OFF±channel leakage current. This bilateral switch/multiplexer/demultiplexer controls analog and digital voltages that may vary across the full power±supply range (from VCC to GND).

The HC4016 is identical in pinout to the metal±gate CMOS MC14016 and MC14066. Each device has four independent switches. The device has been designed so that the ON resistances (RON) are much more linear over input voltage than RON of metal±gate CMOS analog switches.

This device is identical in both function and pinout to the HC4066. The ON/OFF Control inputs are compatible with standard CMOS outputs; with pullup resistors, they are compatible with LSTTL outputs. For analog switches with voltage±level translators, see the HC4316. For analog switches with lower RON characteristics, use the HC4066.

•Fast Switching and Propagation Speeds

•High ON/OFF Output Voltage Ratio

•Low Crosstalk Between Switches

•Diode Protection on All Inputs/Outputs

•Wide Power±Supply Voltage Range (VCC ± GND) = 2.0 to 12.0 Volts

•Analog Input Voltage Range (VCC ± GND) = 2.0 to 12.0 Volts

•Improved Linearity and Lower ON Resistance over Input Voltage than the MC14016 or MC14066

•Low Noise

•Chip Complexity: 32 FETs or 8 Equivalent Gates

		LOGIC DIAGRAM
XA	1	2	YA
XA			YA
A ON/OFF CONTROL	13
XB	4	3	YB
XB			YB
B ON/OFF CONTROL	5		ANALOG
			OUTPUTS/INPUTS
XC	8	9	YC
XC			YC
C ON/OFF CONTROL	6
X	11	10 Y
D			D
D ON/OFF CONTROL	12

ANALOG INPUTS/OUTPUTS = XA, XB, XC, XD

PIN 14 = VCC

PIN 7 = GND

MC54/74HC4016

	J SUFFIX
CERAMIC PACKAGE
14	CASE 632±08
1
	N SUFFIX
PLASTIC PACKAGE
14	CASE 646±06
	CASE 646±06
1
	D SUFFIX
14	SOIC PACKAGE
1	CASE 751A±03
ORDERING INFORMATION
MC54HCXXXXJ	Ceramic
MC74HCXXXXN	Plastic
MC74HCXXXXD	SOIC

PIN ASSIGNMENT

	XA	1
	YA	2
	YB	3
	XB	4
	B ON/OFF	5
	CONTROL	5
	CONTROL
	C ON/OFF	6
	CONTROL
	GND	7

14 VCC

A ON/OFF 13 CONTROL

12 D ON/OFF

CONTROL

11 XD

10 YD

9 YC

8 XC

FUNCTION TABLE

On/Off Control	State of
Input	Analog Switch

L	Off
H	On

10/95

Motorola, Inc. 1995

REV 6

MC54/74HC4016

MAXIMUM RATINGS*

Symbol	Parameter	Value	Unit	This device contains protection
				circuitry to guard against damage
VCC	Positive DC Supply Voltage (Referenced to GND)	± 0.5 to + 14.0	V

				due to high static voltages or electric
VIS	Analog Input Voltage (Referenced to GND)	± 0.5 to VCC + 0.5	V	due to high static voltages or electric
VIS	Analog Input Voltage (Referenced to GND)	± 0.5 to VCC + 0.5	V	fields. However, precautions must
				be taken to avoid applications of any
Vin	Digital Input Voltage (Referenced to GND)	± 1.5 to VCC + 1.5	V	be taken to avoid applications of any
Vin	Digital Input Voltage (Referenced to GND)	± 1.5 to VCC + 1.5	V	voltage higher than maximum rated
I	DC Current Into or Out of Any Pin	± 25	mA	voltages to this high±impedance cir-
				cuit. For proper operation, Vin and
PD	Power Dissipation in Still Air, Plastic or Ceramic DIP²	750	mW	cuit. For proper operation, Vin and
PD	Power Dissipation in Still Air, Plastic or Ceramic DIP²	750	mW	Vout should be constrained to the
	SOIC Package²	500		Vout should be constrained to the
	SOIC Package²	500		range GND v (Vin or Vout) v VCC.
				range GND v (Vin or Vout) v VCC.
Tstg	Storage Temperature	± 65 to + 150	_C	Unused inputs must always be
				tied to an appropriate logic voltage
TL	Lead Temperature, 1 mm from Case for 10 Seconds		_C	tied to an appropriate logic voltage
TL	Lead Temperature, 1 mm from Case for 10 Seconds	260	_C	level (e.g., either GND or VCC).
	(Plastic DIP or SOIC Package)	260		Unused outputs must be left open.
	(Ceramic DIP)	300		Unused outputs must be left open.
	(Ceramic DIP)	300		I/O pins must be connected to a
				I/O pins must be connected to a
* Maximum Ratings are those values beyond which damage to the device may occur.				properly terminated line or bus.
Functional operation should be restricted to the Recommended Operating Conditions.

²Derating	Ð Plastic DIP: ± 10 mW/ _C from 65_ to 125_C
	Ceramic DIP: ± 10 mW/_C from 100_ to 125_C

SOIC Package: ± 7 mW/_C from 65_ to 125_C

For high frequency or heavy load considerations, see Chapter 2 of the Motorola High±Speed CMOS Data Book (DL129/D).

RECOMMENDED OPERATING CONDITIONS

Symbol	Parameter		Min	Max	Unit

VCC	Positive DC Supply Voltage (Referenced to GND)		2.0	12.0	V
VIS	Analog Input Voltage (Referenced to GND)		GND	VCC	V
Vin	Digital Input Voltage (Referenced to GND)		GND	VCC	V
VIO*	Static or Dynamic Voltage Across Switch		Ð	1.2	V
TA	Operating Temperature, All Package Types		± 55	+ 125	_C
tr, tf	Input Rise and Fall Time, ON/OFF	VCC = 2.0 V	0	1000	ns
	Control Inputs (Figure 10)	VCC = 4.5 V	0	500
		VCC = 9.0 V	0	400
	VCC = 12.0 V		0	250

*For voltage drops across the switch greater than 1.2 V (switch on), excessive VCC current may be drawn; i.e., the current out of the switch may contain both VCC and switch input components. The reliability of the device will be unaffected unless the Maximum Ratings are exceeded.

DC ELECTRICAL CHARACTERISTICS Digital Section (Voltages Referenced to GND)

				Guaranteed Limit
			VCC
			VCC	± 55 to
Symbol	Parameter	Test Conditions	V	25_C	v 85_C	v 125_C	Unit

VIH	Minimum High±Level Voltage	Ron = per spec	2.0	1.5	1.5	1.5	V
	ON/OFF Control Inputs		4.5	3.15	3.15	3.15
			9.0	6.3	6.3	6.3
			12.0	8.4	8.4	8.4

VIL	Maximum Low±Level Voltage	Ron = per spec	2.0	0.3	0.3	0.3	V
	ON/OFF Control Inputs		4.5	0.9	0.9	0.9
			9.0	1.8	1.8	1.8
			12.0	2.4	2.4	2.4

Iin	Maximum Input Leakage Current,	Vin = VCC or GND	12.0	±0.1	±1.0	±1.0	μA
	ON/OFF Control Inputs

ICC	Maximum Quiescent Supply	Vin = VCC or GND	6.0	2	20	40	μA
	Current (per Package)	VIO = 0 V	12.0	8	80	160

NOTE: Information on typical parametric values can be found in Chapter 2 of the Motorola High±Speed CMOS Data Book (DL129/D).

MOTOROLA

2

MC54/74HC4016

DC ELECTRICAL CHARACTERISTICS Analog Section (Voltages Referenced to GND)

				Guaranteed Limit
			VCC
			VCC	± 55 to
Symbol	Parameter	Test Conditions	V	25_C	v 85_C	v 125_C	Unit

Ron	Maximum ªONº Resistance	Vin = VIH	2.0²	Ð	Ð	Ð	Ω
		VIS = VCC to GND	4.5	320	400	480
		IS v 2.0 mA (Figures 1, 2)	9.0	170	215	255
			12.0	170	215	255

		Vin = VIH	2.0	Ð	Ð	Ð
		VIS = VCC or GND (Endpoints)	4.5	180	225	270
		IS v 2.0 mA (Figures 1, 2)	9.0	135	170	205
			12.0	135	170	205

Ron	Maximum Difference in ªONº	Vin VIH	2.0	Ð	Ð	Ð	Ω
	Resistance Between Any Two	VIS = 1/2 (VCC ± GND)	4.5	30	35	40
	Channels in the Same Package	IS v 2.0 mA	9.0	20	25	30
			12.0	20	25	30

Ioff	Maximum Off±Channel Leakage	Vin = VIL	12.0	0.1	0.5	1.0	μA
	Current, Any One Channel	VIO = VCC or GND
		Switch Off (Figure 3)

Ion	Maximum On±Channel Leakage	Vin = VIH	12.0	0.1	0.5	1.0	μA
	Current, Any One Channel	VIS = VCC or GND
		(Figure 4)

²At supply voltage (V CC ± GND) approaching 2 V the analog switch±on resistance becomes extremely non±linear. Therefore, for low±voltage operation, it is recommended that these devices only be used to control digital signals.

NOTE: Information on typical parametric values can be found in Chapter 2 of the Motorola High±Speed CMOS Data Book (DL129/D).

AC ELECTRICAL CHARACTERISTICS (CL = 50 pF, ON/OFF Control Inputs: tr = tf = 6 ns)

				Guaranteed Limit
			VCC
			VCC	± 55 to
Symbol		Parameter	V	25_C	v 85_C	v 125_C	Unit

tPLH,	Maximum Propagation Delay, Analog Input to Analog Output		2.0	50	65	75	ns
tPHL	(Figures 8 and 9)		4.5	10	13	15
			9.0	10	13	15
			12.0	10	13	15

tPLZ,	Maximum Propagation Delay, ON/OFF Control to Analog Output		2.0	150	190	225	ns
tPHZ	(Figures 10 and 11)		4.5	30	38	45
			9.0	30	38	45
			12.0	30	38	45

tPZL,	Maximum Propagation Delay, ON/OFF Control to Analog Output		2.0	125	160	185	ns
tPZH	(Figures 10 and 11)		4.5	25	32	37
			9.0	25	32	37
			12.0	25	32	37

C	Maximum Capacitance	ON/OFF Control Input	Ð	10	10	10	pF
		Control Input = GND
		Control Input = GND
		Analog I/O	Ð	35	35	35
		Feedthrough	Ð	1.0	1.0	1.0

NOTES:
1. For propagation delays with loads other than 50 pF, see Chapter 2 of the Motorola High±Speed CMOS Data Book (DL129/D).
2. Information on typical parametric values can be found in Chapter 2 of the Motorola High±Speed CMOS Data Book (DL129/D).

				Typical @ 25°C, VCC = 5.0 V
CPD	Power Dissipation Capacitance (Per Switch)* (Figure 13)				15		pF

* Used to determine the no±load dynamic power consumption: PD = CPD VCC2f + ICC VCC. For load considerations, see Chapter 2 of the Motorola High±Speed CMOS Data Book (DL129/D).

3

MOTOROLA

MC54/74HC4016

ADDITIONAL APPLICATION CHARACTERISTICS (Voltages Referenced to GND unless noted)

				Limit*
			VCC	25_C
Symbol	Parameter	Test Conditions	V	54/74HC	Unit

BW	Maximum On±Channel Bandwidth or	fin = 1 MHz Sine Wave	4.5	150	MHz
	Minimum Frequency Response	Adjust fin Voltage to Obtain 0 dBm at VOS	9.0	160
	(Figure 5)	Increase fin Frequency Until dB Meter Reads ± 3 dB	12.0	160
		RL = 50 Ω, CL = 10 pF
Ð	Off±Channel Feedthrough Isolation	fin Sine Wave	4.5	± 50	dB
	(Figure 6)	Adjust fin Voltage to Obtain 0 dBm at VIS	9.0	± 50
		fin = 10 kHz, RL = 600 Ω, CL = 50 pF	12.0	± 50
		fin = 1.0 MHz, RL = 50 Ω, CL = 10 pF	4.5	± 40
			9.0	± 40
			12.0	± 40

Ð	Feedthrough Noise, Control to Switch	Vin v 1 MHz Square Wave (tr = tf = 6 ns)	4.5	60	mVPP
	(Figure 7)	Adjust RL at Setup so that IS = 0 A	9.0	130
		RL = 600 Ω, CL = 50 pF	12.0	200
		RL = 10 kΩ, CL = 10 pF	4.5	30
			9.0	65
			12.0	100

Ð	Crosstalk Between Any Two Switches	fin Sine Wave	4.5	± 70	dB
	(Figure 12)	Adjust fin Voltage to Obtain 0 dBm at VIS	9.0	± 70
		fin = 10 kHz, RL = 600 Ω, CL = 50 pF	12.0	± 70
		fin = 1.0 MHz, RL = 50 Ω, CL = 10 pF	4.5	± 80
			9.0	± 80
			12.0	± 80

THD	Total Harmonic Distortion	fin = 1 kHz, RL = 10 kΩ, CL = 50 pF			%
	(Figure 14)	THD = THDMeasured ± THDSource
		VIS = 4.0 VPP sine wave	4.5	0.10
		VIS = 8.0 VPP sine wave	9.0	0.06
		VIS = 11.0 VPP sine wave	12.0	0.04

* Guaranteed limits not tested. Determined by design and verified by qualification.

MOTOROLA

4

	3000
					125°C
(OHMS)	2500
(OHMS)	2000
RESISTANCE	2000
	1500			25°C
				25°C

, ON	1000
, ON
on
R	500				± 55°C
	500				± 55°C
	0	.25	.50	.75	1.00	1.25	1.5	1.75	2.00
	0	.25	.50	.75	1.00	1.25	1.5	1.75	2.00
		Vin, INPUT VOLTAGE (VOLTS), REFERENCED TO GND

Figure 1a. Typical On Resistance, VCC = 2.0 V

							MC54/74HC4016
	300
(OHMS)	250
(OHMS)	200
RESISTANCE	200
					125°C
	150
					25°C
, ON	100
, ON					± 55°C
on					± 55°C
R	50
	50
	0	.5	1.0	1.5	2.0	2.5	3.0	3.5	4.0	4.5
	0	.5	1.0	1.5	2.0	2.5	3.0	3.5	4.0	4.5
		Vin, INPUT VOLTAGE (VOLTS), REFERENCED TO GND

Figure 1b. Typical On Resistance, VCC = 4.5 V

	160														120
	140														100
(OHMS)							125°C							(OHMS)	100
	120						125°C								80					125°C
								25°C							80					125°C

RESISTANCE	100													RESISTANCE
RESISTANCE	60													RESISTANCE	60					25°C
	80														60					25°C
								± 55°C
, ON														, ON	40						± 55°C
, ON	40													, ON
on	40													on
on														on	20
R	20													R	20
	20
	0	.5	1.0	1.5	2.0	2.5	3.0	3.5	4.0	4.5	5.0	5.5	6.0		0	1.0	2.0	3.0	4.0	5.0	6.0	7.0	8.0	9.0
	0	.5	1.0	1.5	2.0	2.5	3.0	3.5	4.0	4.5	5.0	5.5	6.0		0	1.0	2.0	3.0	4.0	5.0	6.0	7.0	8.0	9.0
			Vin, INPUT VOLTAGE (VOLTS), REFERENCED TO GND													Vin, INPUT VOLTAGE (VOLTS), REFERENCED TO GND

Figure 1c. Typical On Resistance, VCC = 6.0 V

Figure 1d. Typical On Resistance, VCC = 9.0 V

	80
	70							°
								125 C
(OHMS)	60
(OHMS)	50							25°C
RESISTANCE	50
	40
	30							± 55°C
, ON	20
on	20
on
R	10
	10
	0 0	1.0	2.0	3.0	4.0	5.0	6.0	7.0	8.0	9.0	10.0	11.0	12.0
		Vin, INPUT VOLTAGE (VOLTS), REFERENCED TO GND

PLOTTER

PROGRAMMABLE

POWER MINI COMPUTER DC ANALYZER SUPPLY

±	+	VCC
		VCC
		DEVICE
		UNDER TEST
	ANALOG IN	COMMON OUT
		GND

Figure 1e. Typical On Resistance, VCC = 12.0 V

Figure 2. On Resistance Test Set±Up

5

MOTOROLA
