DICOM PS3.6 2020a - Data Dictionary​

Page 41​

Tag​

Name​

Keyword​

VR​

VM​

(0018,0084)​

Imaging Frequency​

ImagingFrequency​

DS​

1​

(0018,0085)​

Imaged Nucleus​

ImagedNucleus​

SH​

1​

(0018,0086)​

Echo Number(s)​

EchoNumbers​

IS​

1-n​

(0018,0087)​

Magnetic Field Strength​

MagneticFieldStrength​

DS​

1​

(0018,0088)​

Spacing Between Slices​

SpacingBetweenSlices​

DS​

1​

(0018,0089)​ Number of Phase Encoding Steps​NumberOfPhaseEncodingSteps​

IS​

1​

(0018,0090)​

Data Collection Diameter​

DataCollectionDiameter​

DS​

1​

(0018,0091)​

Echo Train Length​

EchoTrainLength​

IS​

1​

(0018,0093)​

Percent Sampling​

PercentSampling​

DS​

1​

(0018,0094)​ Percent Phase Field of View​

PercentPhaseFieldOfView​

DS​

1​

(0018,0095)​

Pixel Bandwidth​

PixelBandwidth​

DS​

1​

(0018,1000)​

Device Serial Number​

DeviceSerialNumber​

LO​

1​

(0018,1002)​

Device UID​

DeviceUID​

UI​

1​

(0018,1003)​

Device ID​

DeviceID​

LO​

1​

(0018,1004)​

Plate ID​

PlateID​

LO​

1​

(0018,1005)​

Generator ID​

GeneratorID​

LO​

1​

(0018,1006)​

Grid ID​

GridID​

LO​

1​

(0018,1007)​

Cassette ID​

CassetteID​

LO​

1​

(0018,1008)​

Gantry ID​

GantryID​

LO​

1​

(0018,1009)​

Unique Device Identifier​

UniqueDeviceIdentifier​

UT​

1​

(0018,100A)​

UDI Sequence​

UDISequence​

SQ​

1​

(0018,100B)​

Manufacturer's Device Class UID​ManufacturerDeviceClassUID​

UI​

1-n​

(0018,1010)​ Secondary Capture Device ID​

SecondaryCaptureDeviceID​

LO​

1​

(0018,1011)​

Hardcopy Creation Device ID​

HardcopyCreationDeviceID​

LO​

1​

RET​

(2007)​

(0018,1012)​ Date of Secondary Capture​

DateOfSecondaryCapture​

DA​

1​

(0018,1014)​ Time of Secondary Capture​

TimeOfSecondaryCapture​

TM​

1​

(0018,1016)​

Secondary Capture Device​

SecondaryCaptureDevice​

LO​

1​

Manufacturer​

Manufacturer​

(0018,1017)​

Hardcopy Device Manufacturer​

HardcopyDeviceManufacturer​

LO​

1​

RET​

(2007)​

(0018,1018)​

Secondary Capture Device​

SecondaryCaptureDevice​

LO​

1​

Manufacturer's Model Name​

ManufacturerModelName​

(0018,1019)​

Secondary Capture Device​

SecondaryCaptureDeviceSoftware​

LO​

1-n​

Software Versions​

Versions​

(0018,101A)​

Hardcopy Device Software Version​HardcopyDeviceSoftwareVersion​

LO​

1-n​

RET​

(2007)​

(0018,101B)​

Hardcopy Device Manufacturer's​ HardcopyDeviceManufacturer​

LO​

1​

RET​

Model Name​

ModelName​

(2007)​

(0018,1020)​

Software Versions​

SoftwareVersions​

LO​

1-n​

(0018,1022)​ Video Image Format Acquired​

VideoImageFormatAcquired​

SH​

1​

(0018,1023)​ Digital Image Format Acquired​

DigitalImageFormatAcquired​

LO​

1​

(0018,1030)​

Protocol Name​

ProtocolName​

LO​

1​

Page 42​

DICOM PS3.6 2020a - Data Dictionary​

Tag​

Name​

Keyword​

VR​

VM​

(0018,1040)​

Contrast/Bolus Route​

ContrastBolusRoute​

LO​

1​

(0018,1041)​

Contrast/Bolus Volume​

ContrastBolusVolume​

DS​

1​

(0018,1042)​

Contrast/Bolus Start Time​

ContrastBolusStartTime​

TM​

1​

(0018,1043)​

Contrast/Bolus Stop Time​

ContrastBolusStopTime​

TM​

1​

(0018,1044)​

Contrast/Bolus Total Dose​

ContrastBolusTotalDose​

DS​

1​

(0018,1045)​

Syringe Counts​

SyringeCounts​

IS​

1​

(0018,1046)​

Contrast Flow Rate​

ContrastFlowRate​

DS​

1-n​

(0018,1047)​

Contrast Flow Duration​

ContrastFlowDuration​

DS​

1-n​

(0018,1048)​

Contrast/Bolus Ingredient​

ContrastBolusIngredient​

CS​

1​

(0018,1049)​

Contrast/Bolus Ingredient​

ContrastBolusIngredient​

DS​

1​

Concentration​

Concentration​

(0018,1050)​

Spatial Resolution​

SpatialResolution​

DS​

1​

(0018,1060)​

Trigger Time​

TriggerTime​

DS​

1​

(0018,1061)​

Trigger Source or Type​

TriggerSourceOrType​

LO​

1​

(0018,1062)​

Nominal Interval​

NominalInterval​

IS​

1​

(0018,1063)​

Frame Time​

FrameTime​

DS​

1​

(0018,1064)​

Cardiac Framing Type​

CardiacFramingType​

LO​

1​

(0018,1065)​

Frame Time Vector​

FrameTimeVector​

DS​

1-n​

(0018,1066)​

Frame Delay​

FrameDelay​

DS​

1​

(0018,1067)​

Image Trigger Delay​

ImageTriggerDelay​

DS​

1​

(0018,1068)​

Multiplex Group Time Offset​

MultiplexGroupTimeOffset​

DS​

1​

(0018,1069)​

Trigger Time Offset​

TriggerTimeOffset​

DS​

1​

(0018,106A)​

Synchronization Trigger​

SynchronizationTrigger​

CS​

1​

(0018,106C)​

Synchronization Channel​

SynchronizationChannel​

US​

2​

(0018,106E)​

Trigger Sample Position​

TriggerSamplePosition​

UL​

1​

(0018,1070)​

Radiopharmaceutical Route​

RadiopharmaceuticalRoute​

LO​

1​

(0018,1071)​

Radiopharmaceutical Volume​

RadiopharmaceuticalVolume​

DS​

1​

(0018,1072)​

Radiopharmaceutical Start Time​

RadiopharmaceuticalStartTime​

TM​

1​

(0018,1073)​

Radiopharmaceutical Stop Time​

RadiopharmaceuticalStopTime​

TM​

1​

(0018,1074)​

Radionuclide Total Dose​

RadionuclideTotalDose​

DS​

1​

(0018,1075)​

Radionuclide Half Life​

RadionuclideHalfLife​

DS​

1​

(0018,1076)​

Radionuclide Positron Fraction​

RadionuclidePositronFraction​

DS​

1​

(0018,1077)​

Radiopharmaceutical Specific​

RadiopharmaceuticalSpecific​

DS​

1​

Activity​

Activity​

(0018,1078)​

Radiopharmaceutical Start​

RadiopharmaceuticalStartDate​

DT​

1​

DateTime​

Time​

(0018,1079)​

Radiopharmaceutical Stop​

RadiopharmaceuticalStopDate​

DT​

1​

DateTime​

Time​

(0018,1080)​

Beat Rejection Flag​

BeatRejectionFlag​

CS​

1​

(0018,1081)​

Low R-R Value​

LowRRValue​

IS​

1​

(0018,1082)​

High R-R Value​

HighRRValue​

IS​

1​

(0018,1083)​

Intervals Acquired​

IntervalsAcquired​

IS​

1​

(0018,1084)​

Intervals Rejected​

IntervalsRejected​

IS​

1​

DICOM PS3.6 2020a - Data Dictionary​

Page 43​

Tag​

Name​

Keyword​

VR​

VM​

(0018,1085)​

PVC Rejection​

PVCRejection​

LO​

1​

(0018,1086)​

Skip Beats​

SkipBeats​

IS​

1​

(0018,1088)​

Heart Rate​

HeartRate​

IS​

1​

(0018,1090)​ Cardiac Number of Images​

CardiacNumberOfImages​

IS​

1​

(0018,1094)​

Trigger Window​

TriggerWindow​

IS​

1​

(0018,1100)​

Reconstruction Diameter​

ReconstructionDiameter​

DS​

1​

(0018,1110)​ Distance Source to Detector​

DistanceSourceToDetector​

DS​

1​

(0018,1111)​ Distance Source to Patient​

DistanceSourceToPatient​

DS​

1​

(0018,1114)​

Estimated Radiographic​

EstimatedRadiographic​

DS​

1​

Magnification Factor​

MagnificationFactor​

(0018,1120)​

Gantry/Detector Tilt​

GantryDetectorTilt​

DS​

1​

(0018,1121)​

Gantry/Detector Slew​

GantryDetectorSlew​

DS​

1​

(0018,1130)​

Table Height​

TableHeight​

DS​

1​

(0018,1131)​

Table Traverse​

TableTraverse​

DS​

1​

(0018,1134)​

Table Motion​

TableMotion​

CS​

1​

(0018,1135)​

Table Vertical Increment​

TableVerticalIncrement​

DS​

1-n​

(0018,1136)​

Table Lateral Increment​

TableLateralIncrement​

DS​

1-n​

(0018,1137)​

Table Longitudinal Increment​

TableLongitudinalIncrement​

DS​

1-n​

(0018,1138)​

Table Angle​

TableAngle​

DS​

1​

(0018,113A)​

Table Type​

TableType​

CS​

1​

(0018,1140)​

Rotation Direction​

RotationDirection​

CS​

1​

(0018,1141)​

Angular Position​

AngularPosition​

DS​

1​

RET​

(2007)​

(0018,1142)​

Radial Position​

RadialPosition​

DS​

1-n​

(0018,1143)​

Scan Arc​

ScanArc​

DS​

1​

(0018,1144)​

Angular Step​

AngularStep​

DS​

1​

(0018,1145)​ Center of Rotation Offset​

CenterOfRotationOffset​

DS​

1​

(0018,1146)​

Rotation Offset​

RotationOffset​

DS​

1-n​

RET​

(1993)​

(0018,1147)​ Field of View Shape​

FieldOfViewShape​

CS​

1​

(0018,1149)​ Field of View Dimension(s)​

FieldOfViewDimensions​

IS​

1-2​

(0018,1150)​

Exposure Time​

ExposureTime​

IS​

1​

(0018,1151)​

X-Ray Tube Current​

XRayTubeCurrent​

IS​

1​

(0018,1152)​

Exposure​

Exposure​

IS​

1​

(0018,1153)​

Exposure in µAs​

ExposureInuAs​

IS​

1​

(0018,1154)​

Average Pulse Width​

AveragePulseWidth​

DS​

1​

(0018,1155)​

Radiation Setting​

RadiationSetting​

CS​

1​

(0018,1156)​

Rectification Type​

RectificationType​

CS​

1​

(0018,115A)​

Radiation Mode​

RadiationMode​

CS​

1​

(0018,115E)​

Image and Fluoroscopy Area Dose​ImageAndFluoroscopyAreaDose​

DS​

1​

Product​

Product​

(0018,1160)​

Filter Type​

FilterType​

SH​

1​

(0018,1161)​

Type of Filters​

TypeOfFilters​

LO​

1-n​

Page 44​

DICOM PS3.6 2020a - Data Dictionary​

Tag​

Name​

Keyword​

VR​

VM​

(0018,1162)​

Intensifier Size​

IntensifierSize​

DS​

1​

(0018,1164)​

Imager Pixel Spacing​

ImagerPixelSpacing​

DS​

2​

(0018,1166)​

Grid​

Grid​

CS​

1-n​

(0018,1170)​

Generator Power​

GeneratorPower​

IS​

1​

(0018,1180)​

Collimator/grid Name​

CollimatorGridName​

SH​

1​

(0018,1181)​

Collimator Type​

CollimatorType​

CS​

1​

(0018,1182)​

Focal Distance​

FocalDistance​

IS​

1-2​

(0018,1183)​

X Focus Center​

XFocusCenter​

DS​

1-2​

(0018,1184)​

Y Focus Center​

YFocusCenter​

DS​

1-2​

(0018,1190)​

Focal Spot(s)​

FocalSpots​

DS​

1-n​

(0018,1191)​

Anode Target Material​

AnodeTargetMaterial​

CS​

1​

(0018,11A0)​

Body Part Thickness​

BodyPartThickness​

DS​

1​

(0018,11A2)​

Compression Force​

CompressionForce​

DS​

1​

(0018,11A3)​

Compression Pressure​

CompressionPressure​

DS​

1​

(0018,11A4)​

Paddle Description​

PaddleDescription​

LO​

1​

(0018,11A5)​

Compression Contact Area​

CompressionContactArea​

DS​

1​

(0018,1200)​

Date of Last Calibration​

DateOfLastCalibration​

DA​

1-n​

(0018,1201)​

Time of Last Calibration​

TimeOfLastCalibration​

TM​

1-n​

(0018,1202)​

DateTime of Last Calibration​

DateTimeOfLastCalibration​

DT​

1​

(0018,1210)​

Convolution Kernel​

ConvolutionKernel​

SH​

1-n​

(0018,1240)​

Upper/Lower Pixel Values​

UpperLowerPixelValues​

IS​

1-n​

RET​

(0018,1242)​

Actual Frame Duration​

ActualFrameDuration​

IS​

1​

(0018,1243)​

Count Rate​

CountRate​

IS​

1​

(0018,1244)​

Preferred Playback Sequencing​

PreferredPlaybackSequencing​

US​

1​

(0018,1250)​

Receive Coil Name​

ReceiveCoilName​

SH​

1​

(0018,1251)​

Transmit Coil Name​

TransmitCoilName​

SH​

1​

(0018,1260)​

Plate Type​

PlateType​

SH​

1​

(0018,1261)​

Phosphor Type​

PhosphorType​

LO​

1​

(0018,1271)​

Water Equivalent Diameter​

WaterEquivalentDiameter​

FD​

1​

(0018,1272)​

Water Equivalent Diameter​

WaterEquivalentDiameter​

SQ​

1​

CalculationMethodCodeSequence​CalculationMethodCodeSequence​

(0018,1300)​

Scan Velocity​

ScanVelocity​

DS​

1​

(0018,1301)​

Whole Body Technique​

WholeBodyTechnique​

CS​

1-n​

(0018,1302)​

Scan Length​

ScanLength​

IS​

1​

(0018,1310)​

Acquisition Matrix​

AcquisitionMatrix​

US​

4​

(0018,1312)​

In-plane Phase Encoding Direction​InPlanePhaseEncodingDirection​

CS​

1​

(0018,1314)​

Flip Angle​

FlipAngle​

DS​

1​

(0018,1315)​

Variable Flip Angle Flag​

VariableFlipAngleFlag​

CS​

1​

(0018,1316)​

SAR​

SAR​

DS​

1​

(0018,1318)​

dB/dt​

dBdt​

DS​

1​

(0018,1320)​

B1rms​

B1rms​

FL​

1​

DICOM PS3.6 2020a - Data Dictionary​

Page 45​

Tag​

Name​

Keyword​

VR​

VM​

(0018,1400)​

Acquisition Device Processing​

AcquisitionDeviceProcessing​

LO​

1​

Description​

Description​

(0018,1401)​

AcquisitionDeviceProcessingCode​AcquisitionDeviceProcessingCode​

LO​

1​

(0018,1402)​

Cassette Orientation​

CassetteOrientation​

CS​

1​

(0018,1403)​

Cassette Size​

CassetteSize​

CS​

1​

(0018,1404)​

Exposures on Plate​

ExposuresOnPlate​

US​

1​

(0018,1405)​

Relative X-Ray Exposure​

RelativeXRayExposure​

IS​

1​

(0018,1411)​

Exposure Index​

ExposureIndex​

DS​

1​

(0018,1412)​

Target Exposure Index​

TargetExposureIndex​

DS​

1​

(0018,1413)​

Deviation Index​

DeviationIndex​

DS​

1​

(0018,1450)​

Column Angulation​

ColumnAngulation​

DS​

1​

(0018,1460)​

Tomo Layer Height​

TomoLayerHeight​

DS​

1​

(0018,1470)​

Tomo Angle​

TomoAngle​

DS​

1​

(0018,1480)​

Tomo Time​

TomoTime​

DS​

1​

(0018,1490)​

Tomo Type​

TomoType​

CS​

1​

(0018,1491)​

Tomo Class​

TomoClass​

CS​

1​

(0018,1495)​

Number of Tomosynthesis Source​NumberOfTomosynthesisSource​

IS​

1​

Images​

Images​

(0018,1500)​

Positioner Motion​

PositionerMotion​

CS​

1​

(0018,1508)​

Positioner Type​

PositionerType​

CS​

1​

(0018,1510)​

Positioner Primary Angle​

PositionerPrimaryAngle​

DS​

1​

(0018,1511)​

Positioner Secondary Angle​

PositionerSecondaryAngle​

DS​

1​

(0018,1520)​

PositionerPrimaryAngleIncrement​PositionerPrimaryAngleIncrement​

DS​

1-n​

(0018,1521)​

Positioner Secondary Angle​

PositionerSecondaryAngle​

DS​

1-n​

Increment​

Increment​

(0018,1530)​

Detector Primary Angle​

DetectorPrimaryAngle​

DS​

1​

(0018,1531)​

Detector Secondary Angle​

DetectorSecondaryAngle​

DS​

1​

(0018,1600)​

Shutter Shape​

ShutterShape​

CS​

1-3​

(0018,1602)​

Shutter Left Vertical Edge​

ShutterLeftVerticalEdge​

IS​

1​

(0018,1604)​

Shutter Right Vertical Edge​

ShutterRightVerticalEdge​

IS​

1​

(0018,1606)​

Shutter Upper Horizontal Edge​

ShutterUpperHorizontalEdge​

IS​

1​

(0018,1608)​

Shutter Lower Horizontal Edge​

ShutterLowerHorizontalEdge​

IS​

1​

(0018,1610)​

Center of Circular Shutter​

CenterOfCircularShutter​

IS​

2​

(0018,1612)​

Radius of Circular Shutter​

RadiusOfCircularShutter​

IS​

1​

(0018,1620)​

Vertices of the Polygonal Shutter​ VerticesOfThePolygonalShutter​

IS​

2-2n​

(0018,1622)​

Shutter Presentation Value​

ShutterPresentationValue​

US​

1​

(0018,1623)​

Shutter Overlay Group​

ShutterOverlayGroup​

US​

1​

(0018,1624)​

Shutter Presentation Color CIELab​ShutterPresentationColorCIELab​

US​

3​

Value​

Value​

(0018,1630)​

Outline Shape Type​

OutlineShapeType​

CS​

1​

(0018,1631)​

Outline Left Vertical Edge​

OutlineLeftVerticalEdge​

FD​

1​

(0018,1632)​

Outline Right Vertical Edge​

OutlineRightVerticalEdge​

FD​

1​

(0018,1633)​

Outline Upper Horizontal Edge​

OutlineUpperHorizontalEdge​

FD​

1​
