DICOM PS3.6 2020a - Data Dictionary​





Page 161​

Tag​

Name​

Keyword​

VR​

VM​



(7Fxx,0040)​

Variable Coefficients SDDN​

VariableCoefficientsSDDN​

OW​

1​

RET​











(2007)​

(FFFA,FFFA)​

Digital Signatures Sequence​

DigitalSignaturesSequence​

SQ​

1​



(FFFC,FFFC)​

Data Set Trailing Padding​

DataSetTrailingPadding​

OB​

1​



(FFFE,E000)​

Item​

Item​

See Note 2​

1​



(FFFE,E00D)​

Item Delimitation Item​

ItemDelimitationItem​

See Note 2​

1​



(FFFE,E0DD)​

Sequence Delimitation Item​

SequenceDelimitationItem​

See Note 2​

1​



Note​

1.​Tag (0040,A170) was defined as Observation Class with a VR of "CS" in the Frozen Draft version of Supplement 23​ "Structured Reporting" (from November 20, 1997). Implementers of the Standard should be warned that old objects of​ the associated SOP Classes exist and that they use this VR instead of "SQ". In particular, when reading objects with​ Implicit VR Little Endian transfer syntax, this inconsistency might result in parsing errors if not handled appropriately.​

2.​The VR for Data Elements, Item (FFFE,E000), Item Delimitation Item (FFFE,E00D), and Sequence Delimitation Item​ (FFFE,E0DD) do not exist. See PS3.5 for explanation.​

3.​For some Data Elements, no Name or Keyword or VR or VM is specified; these are "placeholders" that are not assigned​ but will not be reused.​

- Standard -​

Page 162​

DICOM PS3.6 2020a - Data Dictionary​

- Standard -​

DICOM PS3.6 2020a - Data Dictionary​

Page 163​

7 Registry of DICOM File Meta Elements​

This section specifies the File Meta Elements needed to support the formatting of the File Meta Information of the DICOM File Format​

(see PS3.10).​

Table 7-1. Registry of DICOM File Meta Elements​

Tag​

Name​

Keyword​

VR​

VM​

(0002,0000)​

File Meta Information Group Length​FileMetaInformationGroupLength​

UL​

1​

(0002,0001)​

File Meta Information Version​

FileMetaInformationVersion​

OB​

1​

(0002,0002)​

Media Storage SOP Class UID​

MediaStorageSOPClassUID​

UI​

1​

(0002,0003)​

Media Storage SOP Instance UID​

MediaStorageSOPInstanceUID​

UI​

1​

(0002,0010)​

Transfer Syntax UID​

TransferSyntaxUID​

UI​

1​

(0002,0012)​

Implementation Class UID​

ImplementationClassUID​

UI​

1​

(0002,0013)​

Implementation Version Name​

ImplementationVersionName​

SH​

1​

(0002,0016)​

Source Application Entity Title​

SourceApplicationEntityTitle​

AE​

1​

(0002,0017)​

Sending Application Entity Title​

SendingApplicationEntityTitle​

AE​

1​

(0002,0018)​

Receiving Application Entity Title​

ReceivingApplicationEntityTitle​

AE​

1​

(0002,0026)​

Source Presentation Address​

SourcePresentationAddress​

UR​

1​

(0002,0027)​

Sending Presentation Address​

SendingPresentationAddress​

UR​

1​

(0002,0028)​

Receiving Presentation Address​

ReceivingPresentationAddress​

UR​

1​

(0002,0031)​

RTV Meta Information Version​

RTVMetaInformationVersion​

OB​

1​

(0002,0032)​

RTV Communication SOP Class UID​RTVCommunicationSOPClassUID​

UI​

1​

(0002,0033)​

RTV Communication SOP Instance​RTVCommunicationSOPInstanceUID​

UI​

1​



UID​







(0002,0035)​

RTV Source Identifier​

RTVSourceIdentifier​

OB​

1​

(0002,0036)​

RTV Flow Identifier​

RTVFlowIdentifier​

OB​

1​

(0002,0037)​

RTV Flow RTP Sampling Rate​

RTVFlowRTPSamplingRate​

UL​

1​

(0002,0038)​

RTV Flow Actual Frame Duration​

RTVFlowActualFrameDuration​

FD​

1​

(0002,0100)​

Private Information Creator UID​

PrivateInformationCreatorUID​

UI​

1​

(0002,0102)​

Private Information​

PrivateInformation​

OB​

1​

- Standard -​

Page 164​

DICOM PS3.6 2020a - Data Dictionary​

- Standard -​

DICOM PS3.6 2020a - Data Dictionary​

Page 165​

8 Registry of DICOM Directory Structuring​

Elements​

For retired elements, the last edition of the Standard that documented the element is indicated in parentheses.​

Table 8-1. Registry of DICOM Directory Structuring Elements​

Tag​

Name​

Keyword​

VR​

VM​



(0004,1130)​

File-set ID​

FileSetID​

CS​

1​



(0004,1141)​ File-set Descriptor File ID​

FileSetDescriptorFileID​

CS​

1-8​



(0004,1142)​ Specific Character Set of File-set​

SpecificCharacterSetOfFileSet​

CS​

1​





Descriptor File​

DescriptorFile​







(0004,1200)​ Offset of the First Directory Record​OffsetOfTheFirstDirectoryRecordOf​

UL​

1​





of the Root Directory Entity​

TheRootDirectoryEntity​







(0004,1202)​ Offset of the Last Directory Record​OffsetOfTheLastDirectoryRecordOf​

UL​

1​





of the Root Directory Entity​

TheRootDirectoryEntity​







(0004,1212)​

File-set Consistency Flag​

FileSetConsistencyFlag​

US​

1​



(0004,1220)​

Directory Record Sequence​

DirectoryRecordSequence​

SQ​

1​



(0004,1400)​ Offset of the Next Directory Record​OffsetOfTheNextDirectoryRecord​

UL​

1​



(0004,1410)​

Record In-use Flag​

RecordInUseFlag​

US​

1​



(0004,1420)​ Offset of Referenced Lower-Level​

OffsetOfReferencedLowerLevel​

UL​

1​





Directory Entity​

DirectoryEntity​







(0004,1430)​

Directory Record Type​

DirectoryRecordType​

CS​

1​



(0004,1432)​

Private Record UID​

PrivateRecordUID​

UI​

1​



(0004,1500)​

Referenced File ID​

ReferencedFileID​

CS​

1-8​



(0004,1504)​ MRDR Directory Record Offset​

MRDRDirectoryRecordOffset​

UL​

1​

RET​











(2004)​

(0004,1510)​ Referenced SOP Class UID in File​ReferencedSOPClassUIDInFile​

UI​

1​



(0004,1511)​ ReferencedSOPInstanceUIDinFile​ReferencedSOPInstanceUIDInFile​

UI​

1​



(0004,1512)​ Referenced Transfer Syntax UID in​ReferencedTransferSyntaxUIDInFile​

UI​

1​





File​









(0004,151A)​

Referenced Related General SOP​ ReferencedRelatedGeneralSOP​

UI​

1-n​





Class UID in File​

ClassUIDInFile​







(0004,1600)​

Number of References​

NumberOfReferences​

UL​

1​

RET​











(2004)​

- Standard -​
