DICOM PS3.6 2020a - Data Dictionary​

Page 131​

Tag​

Name​

Keyword​

VR​

VM​

(3008,0050)​

Treatment Summary Calculated​

TreatmentSummaryCalculated​

SQ​

1​

Dose Reference Sequence​

DoseReferenceSequence​

(3008,0052)​

Cumulative Dose to Dose​

CumulativeDoseToDoseReference​

DS​

1​

Reference​

(3008,0054)​

First Treatment Date​

FirstTreatmentDate​

DA​

1​

(3008,0056)​

Most Recent Treatment Date​

MostRecentTreatmentDate​

DA​

1​

(3008,005A)​ Number of Fractions Delivered​

NumberOfFractionsDelivered​

IS​

1​

(3008,0060)​

Override Sequence​

OverrideSequence​

SQ​

1​

(3008,0061)​

Parameter Sequence Pointer​

ParameterSequencePointer​

AT​

1​

(3008,0062)​

Override Parameter Pointer​

OverrideParameterPointer​

AT​

1​

(3008,0063)​

Parameter Item Index​

ParameterItemIndex​

IS​

1​

(3008,0064)​

MeasuredDoseReferenceNumber​MeasuredDoseReferenceNumber​

IS​

1​

(3008,0065)​

Parameter Pointer​

ParameterPointer​

AT​

1​

(3008,0066)​

Override Reason​

OverrideReason​

ST​

1​

(3008,0067)​

Parameter Value Number​

ParameterValueNumber​

US​

1​

(3008,0068)​

Corrected Parameter Sequence​

CorrectedParameterSequence​

SQ​

1​

(3008,006A)​

Correction Value​

CorrectionValue​

FL​

1​

(3008,0070)​

Calculated Dose Reference​

CalculatedDoseReference​

SQ​

1​

Sequence​

Sequence​

(3008,0072)​

CalculatedDoseReferenceNumber​CalculatedDoseReferenceNumber​

IS​

1​

(3008,0074)​

Calculated Dose Reference​

CalculatedDoseReference​

ST​

1​

Description​

Description​

(3008,0076)​

Calculated Dose Reference Dose​CalculatedDoseReferenceDose​

DS​

1​

Value​

Value​

(3008,0078)​

Start Meterset​

StartMeterset​

DS​

1​

(3008,007A)​

End Meterset​

EndMeterset​

DS​

1​

(3008,0080)​

Referenced Measured Dose​

ReferencedMeasuredDose​

SQ​

1​

Reference Sequence​

ReferenceSequence​

(3008,0082)​

Referenced Measured Dose​

ReferencedMeasuredDose​

IS​

1​

Reference Number​

ReferenceNumber​

(3008,0090)​

Referenced Calculated Dose​

ReferencedCalculatedDose​

SQ​

1​

Reference Sequence​

ReferenceSequence​

(3008,0092)​

Referenced Calculated Dose​

ReferencedCalculatedDose​

IS​

1​

Reference Number​

ReferenceNumber​

(3008,00A0)​ Beam Limiting Device Leaf Pairs​

BeamLimitingDeviceLeafPairs​

SQ​

1​

Sequence​

Sequence​

(3008,00B0)​

Recorded Wedge Sequence​

RecordedWedgeSequence​

SQ​

1​

(3008,00C0)​

Recorded Compensator Sequence​RecordedCompensatorSequence​

SQ​

1​

(3008,00D0)​

Recorded Block Sequence​

RecordedBlockSequence​

SQ​

1​

(3008,00E0)​

Treatment Summary Measured​

TreatmentSummaryMeasuredDose​

SQ​

1​

Dose Reference Sequence​

ReferenceSequence​

(3008,00F0)​

Recorded Snout Sequence​

RecordedSnoutSequence​

SQ​

1​

(3008,00F2)​

RecordedRangeShifterSequence​RecordedRangeShifterSequence​

SQ​

1​

(3008,00F4)​

RecordedLateralSpreadingDevice​RecordedLateralSpreadingDevice​

SQ​

1​

Sequence​

Sequence​

Page 132​

DICOM PS3.6 2020a - Data Dictionary​

Tag​

Name​

Keyword​

VR​

VM​

(3008,00F6)​

Recorded Range Modulator​

RecordedRangeModulator​

SQ​

1​

Sequence​

Sequence​

(3008,0100)​

Recorded Source Sequence​

RecordedSourceSequence​

SQ​

1​

(3008,0105)​

Source Serial Number​

SourceSerialNumber​

LO​

1​

(3008,0110)​

Treatment Session Application​

TreatmentSessionApplicationSetup​

SQ​

1​

Setup Sequence​

Sequence​

(3008,0116)​

Application Setup Check​

ApplicationSetupCheck​

CS​

1​

(3008,0120)​

RecordedBrachyAccessoryDevice​RecordedBrachyAccessoryDevice​

SQ​

1​

Sequence​

Sequence​

(3008,0122)​

Referenced Brachy Accessory​

ReferencedBrachyAccessory​

IS​

1​

Device Number​

DeviceNumber​

(3008,0130)​

Recorded Channel Sequence​

RecordedChannelSequence​

SQ​

1​

(3008,0132)​

Specified Channel Total Time​

SpecifiedChannelTotalTime​

DS​

1​

(3008,0134)​

Delivered Channel Total Time​

DeliveredChannelTotalTime​

DS​

1​

(3008,0136)​

Specified Number of Pulses​

SpecifiedNumberOfPulses​

IS​

1​

(3008,0138)​

Delivered Number of Pulses​

DeliveredNumberOfPulses​

IS​

1​

(3008,013A)​ Specified Pulse Repetition Interval​SpecifiedPulseRepetitionInterval​

DS​

1​

(3008,013C)​

Delivered Pulse Repetition Interval​DeliveredPulseRepetitionInterval​

DS​

1​

(3008,0140)​

Recorded Source Applicator​

RecordedSourceApplicator​

SQ​

1​

Sequence​

Sequence​

(3008,0142)​

Referenced Source Applicator​

ReferencedSourceApplicator​

IS​

1​

Number​

Number​

(3008,0150)​

Recorded Channel Shield​

RecordedChannelShieldSequence​

SQ​

1​

Sequence​

(3008,0152)​

ReferencedChannelShieldNumber​ReferencedChannelShieldNumber​

IS​

1​

(3008,0160)​

Brachy Control Point Delivered​

BrachyControlPointDelivered​

SQ​

1​

Sequence​

Sequence​

(3008,0162)​

Safe Position Exit Date​

SafePositionExitDate​

DA​

1​

(3008,0164)​

Safe Position Exit Time​

SafePositionExitTime​

TM​

1​

(3008,0166)​

Safe Position Return Date​

SafePositionReturnDate​

DA​

1​

(3008,0168)​

Safe Position Return Time​

SafePositionReturnTime​

TM​

1​

(3008,0171)​

PulseSpecificBrachyControlPoint​PulseSpecificBrachyControlPoint​

SQ​

1​

Delivered Sequence​

DeliveredSequence​

(3008,0172)​

Pulse Number​

PulseNumber​

US​

1​

(3008,0173)​

Brachy Pulse Control Point​

BrachyPulseControlPointDelivered​

SQ​

1​

Delivered Sequence​

Sequence​

(3008,0200)​

Current Treatment Status​

CurrentTreatmentStatus​

CS​

1​

(3008,0202)​

Treatment Status Comment​

TreatmentStatusComment​

ST​

1​

(3008,0220)​

FractionGroupSummarySequence​FractionGroupSummarySequence​

SQ​

1​

(3008,0223)​

Referenced Fraction Number​

ReferencedFractionNumber​

IS​

1​

(3008,0224)​

Fraction Group Type​

FractionGroupType​

CS​

1​

(3008,0230)​

Beam Stopper Position​

BeamStopperPosition​

CS​

1​

(3008,0240)​

FractionStatusSummarySequence​FractionStatusSummarySequence​

SQ​

1​

(3008,0250)​

Treatment Date​

TreatmentDate​

DA​

1​

DICOM PS3.6 2020a - Data Dictionary​

Page 133​

Tag​

Name​

Keyword​

VR​

VM​

(3008,0251)​

Treatment Time​

TreatmentTime​

TM​

1​

(300A,0002)​

RT Plan Label​

RTPlanLabel​

SH​

1​

(300A,0003)​

RT Plan Name​

RTPlanName​

LO​

1​

(300A,0004)​

RT Plan Description​

RTPlanDescription​

ST​

1​

(300A,0006)​

RT Plan Date​

RTPlanDate​

DA​

1​

(300A,0007)​

RT Plan Time​

RTPlanTime​

TM​

1​

(300A,0009)​

Treatment Protocols​

TreatmentProtocols​

LO​

1-n​

(300A,000A)​

Plan Intent​

PlanIntent​

CS​

1​

(300A,000B)​

Treatment Sites​

TreatmentSites​

LO​

1-n​

(300A,000C)​

RT Plan Geometry​

RTPlanGeometry​

CS​

1​

(300A,000E)​

Prescription Description​

PrescriptionDescription​

ST​

1​

(300A,0010)​

Dose Reference Sequence​

DoseReferenceSequence​

SQ​

1​

(300A,0012)​

Dose Reference Number​

DoseReferenceNumber​

IS​

1​

(300A,0013)​

Dose Reference UID​

DoseReferenceUID​

UI​

1​

(300A,0014)​

Dose Reference Structure Type​

DoseReferenceStructureType​

CS​

1​

(300A,0015)​

Nominal Beam Energy Unit​

NominalBeamEnergyUnit​

CS​

1​

(300A,0016)​

Dose Reference Description​

DoseReferenceDescription​

LO​

1​

(300A,0018)​

Dose Reference Point Coordinates​DoseReferencePointCoordinates​

DS​

3​

(300A,001A)​

Nominal Prior Dose​

NominalPriorDose​

DS​

1​

(300A,0020)​

Dose Reference Type​

DoseReferenceType​

CS​

1​

(300A,0021)​

Constraint Weight​

ConstraintWeight​

DS​

1​

(300A,0022)​

Delivery Warning Dose​

DeliveryWarningDose​

DS​

1​

(300A,0023)​

Delivery Maximum Dose​

DeliveryMaximumDose​

DS​

1​

(300A,0025)​

Target Minimum Dose​

TargetMinimumDose​

DS​

1​

(300A,0026)​

Target Prescription Dose​

TargetPrescriptionDose​

DS​

1​

(300A,0027)​

Target Maximum Dose​

TargetMaximumDose​

DS​

1​

(300A,0028)​

TargetUnderdoseVolumeFraction​TargetUnderdoseVolumeFraction​

DS​

1​

(300A,002A)​

Organ at Risk Full-volume Dose​

OrganAtRiskFullVolumeDose​

DS​

1​

(300A,002B)​

Organ at Risk Limit Dose​

OrganAtRiskLimitDose​

DS​

1​

(300A,002C)​

Organ at Risk Maximum Dose​

OrganAtRiskMaximumDose​

DS​

1​

(300A,002D)​

Organ at Risk Overdose Volume​

OrganAtRiskOverdoseVolume​

DS​

1​

Fraction​

Fraction​

(300A,0040)​

Tolerance Table Sequence​

ToleranceTableSequence​

SQ​

1​

(300A,0042)​

Tolerance Table Number​

ToleranceTableNumber​

IS​

1​

(300A,0043)​

Tolerance Table Label​

ToleranceTableLabel​

SH​

1​

(300A,0044)​

Gantry Angle Tolerance​

GantryAngleTolerance​

DS​

1​

(300A,0046)​

Beam Limiting Device Angle​

BeamLimitingDeviceAngle​

DS​

1​

Tolerance​

Tolerance​

(300A,0048)​

Beam Limiting Device Tolerance​

BeamLimitingDeviceTolerance​

SQ​

1​

Sequence​

Sequence​

(300A,004A)​

Beam Limiting Device Position​

BeamLimitingDevicePosition​

DS​

1​

Tolerance​

Tolerance​

(300A,004B)​

Snout Position Tolerance​

SnoutPositionTolerance​

FL​

1​

Page 134​

DICOM PS3.6 2020a - Data Dictionary​

Tag​

Name​

Keyword​

VR​

VM​

(300A,004C)​

Patient Support Angle Tolerance​

PatientSupportAngleTolerance​

DS​

1​

(300A,004E)​

Table Top Eccentric Angle​

TableTopEccentricAngleTolerance​

DS​

1​

Tolerance​

(300A,004F)​ Table Top Pitch Angle Tolerance​ TableTopPitchAngleTolerance​

FL​

1​

(300A,0050)​

Table Top Roll Angle Tolerance​

TableTopRollAngleTolerance​

FL​

1​

(300A,0051)​

Table Top Vertical Position​

TableTopVerticalPositionTolerance​

DS​

1​

Tolerance​

(300A,0052)​

Table Top Longitudinal Position​

TableTopLongitudinalPosition​

DS​

1​

Tolerance​

Tolerance​

(300A,0053)​

Table Top Lateral Position​

TableTopLateralPositionTolerance​

DS​

1​

Tolerance​

(300A,0055)​

RT Plan Relationship​

RTPlanRelationship​

CS​

1​

(300A,0070)​

Fraction Group Sequence​

FractionGroupSequence​

SQ​

1​

(300A,0071)​

Fraction Group Number​

FractionGroupNumber​

IS​

1​

(300A,0072)​

Fraction Group Description​

FractionGroupDescription​

LO​

1​

(300A,0078)​

Number of Fractions Planned​

NumberOfFractionsPlanned​

IS​

1​

(300A,0079)​

Number of Fraction Pattern Digits​NumberOfFractionPatternDigitsPer​

IS​

1​

Per Day​

Day​

(300A,007A)​

Repeat Fraction Cycle Length​

RepeatFractionCycleLength​

IS​

1​

(300A,007B)​

Fraction Pattern​

FractionPattern​

LT​

1​

(300A,0080)​

Number of Beams​

NumberOfBeams​

IS​

1​

(300A,0082)​

Beam Dose Specification Point​

BeamDoseSpecificationPoint​

DS​

3​

RET​

(2019c)​

(300A,0083)​

Referenced Dose Reference UID​ReferencedDoseReferenceUID​

UI​

1​

(300A,0084)​

Beam Dose​

BeamDose​

DS​

1​

(300A,0086)​

Beam Meterset​

BeamMeterset​

DS​

1​

(300A,0088)​

Beam Dose Point Depth​

BeamDosePointDepth​

FL​

1​

(300A,0089)​

BeamDosePointEquivalentDepth​BeamDosePointEquivalentDepth​

FL​

1​

(300A,008A)​

Beam Dose Point SSD​

BeamDosePointSSD​

FL​

1​

(300A,008B)​

Beam Dose Meaning​

BeamDoseMeaning​

CS​

1​

(300A,008C)​

Beam Dose Verification Control​

BeamDoseVerificationControlPoint​

SQ​

1​

Point Sequence​

Sequence​

(300A,008D)​

Average Beam Dose Point Depth​AverageBeamDosePointDepth​

FL​

1​

RET​

(2017c)​

(300A,008E)​

Average Beam Dose Point​

AverageBeamDosePointEquivalent​

FL​

1​

RET​

Equivalent Depth​

Depth​

(2017c)​

(300A,008F)​

Average Beam Dose Point SSD​

AverageBeamDosePointSSD​

FL​

1​

RET​

(2017c)​

(300A,0090)​

Beam Dose Type​

BeamDoseType​

CS​

1​

(300A,0091)​

Alternate Beam Dose​

AlternateBeamDose​

DS​

1​

(300A,0092)​

Alternate Beam Dose Type​

AlternateBeamDoseType​

CS​

1​

(300A,0093)​

Depth Value Averaging Flag​

DepthValueAveragingFlag​

CS​

1​

(300A,0094)​

Beam Dose Point Source to​

BeamDosePointSourceToExternal​

DS​

1​

External Contour Distance​

ContourDistance​

DICOM PS3.6 2020a - Data Dictionary​

Page 135​

Tag​

Name​

Keyword​

VR​

VM​

(300A,00A0)​

Number of Brachy Application​

NumberOfBrachyApplication​

IS​

1​

Setups​

Setups​

(300A,00A2)​

Brachy Application Setup Dose​

BrachyApplicationSetupDose​

DS​

3​

Specification Point​

SpecificationPoint​

(300A,00A4)​

Brachy Application Setup Dose​

BrachyApplicationSetupDose​

DS​

1​

(300A,00B0)​

Beam Sequence​

BeamSequence​

SQ​

1​

(300A,00B2)​

Treatment Machine Name​

TreatmentMachineName​

SH​

1​

(300A,00B3)​

Primary Dosimeter Unit​

PrimaryDosimeterUnit​

CS​

1​

(300A,00B4)​

Source-Axis Distance​

SourceAxisDistance​

DS​

1​

(300A,00B6)​

Beam Limiting Device Sequence​

BeamLimitingDeviceSequence​

SQ​

1​

(300A,00B8)​

RT Beam Limiting Device Type​

RTBeamLimitingDeviceType​

CS​

1​

(300A,00BA)​

Source to Beam Limiting Device​

SourceToBeamLimitingDevice​

DS​

1​

Distance​

Distance​

(300A,00BB)​

Isocenter to Beam Limiting Device​IsocenterToBeamLimitingDevice​

FL​

1​

Distance​

Distance​

(300A,00BC)​

Number of Leaf/Jaw Pairs​

NumberOfLeafJawPairs​

IS​

1​

(300A,00BE)​

Leaf Position Boundaries​

LeafPositionBoundaries​

DS​

3-n​

(300A,00C0)​

Beam Number​

BeamNumber​

IS​

1​

(300A,00C2)​

Beam Name​

BeamName​

LO​

1​

(300A,00C3)​

Beam Description​

BeamDescription​

ST​

1​

(300A,00C4)​

Beam Type​

BeamType​

CS​

1​

(300A,00C5)​

Beam Delivery Duration Limit​

BeamDeliveryDurationLimit​

FD​

1​

(300A,00C6)​

Radiation Type​

RadiationType​

CS​

1​

(300A,00C7)​

High-Dose Technique Type​

HighDoseTechniqueType​

CS​

1​

(300A,00C8)​

Reference Image Number​

ReferenceImageNumber​

IS​

1​

(300A,00CA)​

Planned Verification Image​

PlannedVerificationImage​

SQ​

1​

Sequence​

Sequence​

(300A,00CC)​

ImagingDevice-SpecificAcquisition​ImagingDeviceSpecificAcquisition​

LO​

1-n​

Parameters​

Parameters​

(300A,00CE)​

Treatment Delivery Type​

TreatmentDeliveryType​

CS​

1​

(300A,00D0)​

Number of Wedges​

NumberOfWedges​

IS​

1​

(300A,00D1)​

Wedge Sequence​

WedgeSequence​

SQ​

1​

(300A,00D2)​

Wedge Number​

WedgeNumber​

IS​

1​

(300A,00D3)​

Wedge Type​

WedgeType​

CS​

1​

(300A,00D4)​

Wedge ID​

WedgeID​

SH​

1​

(300A,00D5)​

Wedge Angle​

WedgeAngle​

IS​

1​

(300A,00D6)​

Wedge Factor​

WedgeFactor​

DS​

1​

(300A,00D7)​

TotalWedgeTrayWater-Equivalent​TotalWedgeTrayWaterEquivalent​

FL​

1​

Thickness​

Thickness​

(300A,00D8)​

Wedge Orientation​

WedgeOrientation​

DS​

1​

(300A,00D9)​

Isocenter to Wedge Tray Distance​IsocenterToWedgeTrayDistance​

FL​

1​

(300A,00DA)​

Source to Wedge Tray Distance​

SourceToWedgeTrayDistance​

DS​

1​

(300A,00DB)​

Wedge Thin Edge Position​

WedgeThinEdgePosition​

FL​

1​

(300A,00DC)​

Bolus ID​

BolusID​

SH​

1​
