DICOM PS3.6 2020a - Data Dictionary​

Page 101​

Tag​

Name​

Keyword​

VR​

VM​

(0048,0207)​

Optical Path Identification​

OpticalPathIdentificationSequence​

SQ​

1​

Sequence​

(0048,021A)​

Plane Position (Slide) Sequence​ PlanePositionSlideSequence​

SQ​

1​

(0048,021E)​

Column Position In Total Image​

ColumnPositionInTotalImagePixel​

SL​

1​

Pixel Matrix​

Matrix​

(0048,021F)​ Row Position In Total Image Pixel​RowPositionInTotalImagePixel​

SL​

1​

Matrix​

Matrix​

(0048,0301)​

Pixel Origin Interpretation​

PixelOriginInterpretation​

CS​

1​

(0048,0302)​

Number of Optical Paths​

NumberOfOpticalPaths​

UL​

1​

(0048,0303)​

Total Pixel Matrix Focal Planes​

TotalPixelMatrixFocalPlanes​

UL​

1​

(0050,0004)​

Calibration Image​

CalibrationImage​

CS​

1​

(0050,0010)​

Device Sequence​

DeviceSequence​

SQ​

1​

(0050,0012)​

Container Component Type Code​ContainerComponentTypeCode​

SQ​

1​

Sequence​

Sequence​

(0050,0013)​

Container Component Thickness​ ContainerComponentThickness​

FD​

1​

(0050,0014)​

Device Length​

DeviceLength​

DS​

1​

(0050,0015)​

Container Component Width​

ContainerComponentWidth​

FD​

1​

(0050,0016)​

Device Diameter​

DeviceDiameter​

DS​

1​

(0050,0017)​

Device Diameter Units​

DeviceDiameterUnits​

CS​

1​

(0050,0018)​

Device Volume​

DeviceVolume​

DS​

1​

(0050,0019)​

Inter-Marker Distance​

InterMarkerDistance​

DS​

1​

(0050,001A)​

Container Component Material​

ContainerComponentMaterial​

CS​

1​

(0050,001B)​

Container Component ID​

ContainerComponentID​

LO​

1​

(0050,001C)​

Container Component Length​

ContainerComponentLength​

FD​

1​

(0050,001D)​

Container Component Diameter​

ContainerComponentDiameter​

FD​

1​

(0050,001E)​

Container Component Description​ContainerComponentDescription​

LO​

1​

(0050,0020)​

Device Description​

DeviceDescription​

LO​

1​

(0050,0021)​

Long Device Description​

LongDeviceDescription​

ST​

1​

(0052,0001)​

Contrast/Bolus Ingredient Percent​ContrastBolusIngredientPercentBy​

FL​

1​

by Volume​

Volume​

(0052,0002)​

OCT Focal Distance​

OCTFocalDistance​

FD​

1​

(0052,0003)​

Beam Spot Size​

BeamSpotSize​

FD​

1​

(0052,0004)​

Effective Refractive Index​

EffectiveRefractiveIndex​

FD​

1​

(0052,0006)​

OCT Acquisition Domain​

OCTAcquisitionDomain​

CS​

1​

(0052,0007)​

OCT Optical Center Wavelength​

OCTOpticalCenterWavelength​

FD​

1​

(0052,0008)​

Axial Resolution​

AxialResolution​

FD​

1​

(0052,0009)​

Ranging Depth​

RangingDepth​

FD​

1​

(0052,0011)​

A-line Rate​

ALineRate​

FD​

1​

(0052,0012)​

A-lines Per Frame​

ALinesPerFrame​

US​

1​

(0052,0013)​

Catheter Rotational Rate​

CatheterRotationalRate​

FD​

1​

(0052,0014)​

A-line Pixel Spacing​

ALinePixelSpacing​

FD​

1​

(0052,0016)​

Mode of Percutaneous Access​

ModeOfPercutaneousAccess​

SQ​

1​

Sequence​

Sequence​

Page 102​

DICOM PS3.6 2020a - Data Dictionary​

Tag​

Name​

Keyword​

VR​

VM​

(0052,0025)​

Intravascular OCT Frame Type​

IntravascularOCTFrameType​

SQ​

1​

Sequence​

Sequence​

(0052,0026)​

OCT Z Offset Applied​

OCTZOffsetApplied​

CS​

1​

(0052,0027)​

Intravascular Frame Content​

IntravascularFrameContent​

SQ​

1​

Sequence​

Sequence​

(0052,0028)​

IntravascularLongitudinalDistance​IntravascularLongitudinalDistance​

FD​

1​

(0052,0029)​

Intravascular OCT Frame Content​IntravascularOCTFrameContent​

SQ​

1​

Sequence​

Sequence​

(0052,0030)​

OCT Z Offset Correction​

OCTZOffsetCorrection​

SS​

1​

(0052,0031)​

Catheter Direction of Rotation​

CatheterDirectionOfRotation​

CS​

1​

(0052,0033)​

Seam Line Location​

SeamLineLocation​

FD​

1​

(0052,0034)​

First A-line Location​

FirstALineLocation​

FD​

1​

(0052,0036)​

Seam Line Index​

SeamLineIndex​

US​

1​

(0052,0038)​

Number of Padded A-lines​

NumberOfPaddedALines​

US​

1​

(0052,0039)​

Interpolation Type​

InterpolationType​

CS​

1​

(0052,003A)​

Refractive Index Applied​

RefractiveIndexApplied​

CS​

1​

(0054,0010)​

Energy Window Vector​

EnergyWindowVector​

US​

1-n​

(0054,0011)​

Number of Energy Windows​

NumberOfEnergyWindows​

US​

1​

(0054,0012)​

Energy Window Information​

EnergyWindowInformation​

SQ​

1​

Sequence​

Sequence​

(0054,0013)​

Energy Window Range Sequence​EnergyWindowRangeSequence​

SQ​

1​

(0054,0014)​

Energy Window Lower Limit​

EnergyWindowLowerLimit​

DS​

1​

(0054,0015)​

Energy Window Upper Limit​

EnergyWindowUpperLimit​

DS​

1​

(0054,0016)​

Radiopharmaceutical Information​RadiopharmaceuticalInformation​

SQ​

1​

Sequence​

Sequence​

(0054,0017)​

Residual Syringe Counts​

ResidualSyringeCounts​

IS​

1​

(0054,0018)​

Energy Window Name​

EnergyWindowName​

SH​

1​

(0054,0020)​

Detector Vector​

DetectorVector​

US​

1-n​

(0054,0021)​

Number of Detectors​

NumberOfDetectors​

US​

1​

(0054,0022)​

Detector Information Sequence​

DetectorInformationSequence​

SQ​

1​

(0054,0030)​

Phase Vector​

PhaseVector​

US​

1-n​

(0054,0031)​

Number of Phases​

NumberOfPhases​

US​

1​

(0054,0032)​

Phase Information Sequence​

PhaseInformationSequence​

SQ​

1​

(0054,0033)​

Number of Frames in Phase​

NumberOfFramesInPhase​

US​

1​

(0054,0036)​

Phase Delay​

PhaseDelay​

IS​

1​

(0054,0038)​

Pause Between Frames​

PauseBetweenFrames​

IS​

1​

(0054,0039)​

Phase Description​

PhaseDescription​

CS​

1​

(0054,0050)​

Rotation Vector​

RotationVector​

US​

1-n​

(0054,0051)​

Number of Rotations​

NumberOfRotations​

US​

1​

(0054,0052)​

Rotation Information Sequence​

RotationInformationSequence​

SQ​

1​

(0054,0053)​

Number of Frames in Rotation​

NumberOfFramesInRotation​

US​

1​

(0054,0060)​

R-R Interval Vector​

RRIntervalVector​

US​

1-n​

(0054,0061)​

Number of R-R Intervals​

NumberOfRRIntervals​

US​

1​

DICOM PS3.6 2020a - Data Dictionary​

Page 103​

Tag​

Name​

Keyword​

VR​

VM​

(0054,0062)​

Gated Information Sequence​

GatedInformationSequence​

SQ​

1​

(0054,0063)​

Data Information Sequence​

DataInformationSequence​

SQ​

1​

(0054,0070)​

Time Slot Vector​

TimeSlotVector​

US​

1-n​

(0054,0071)​ Number of Time Slots​

NumberOfTimeSlots​

US​

1​

(0054,0072)​ Time Slot Information Sequence​

TimeSlotInformationSequence​

SQ​

1​

(0054,0073)​

Time Slot Time​

TimeSlotTime​

DS​

1​

(0054,0080)​

Slice Vector​

SliceVector​

US​

1-n​

(0054,0081)​

Number of Slices​

NumberOfSlices​

US​

1​

(0054,0090)​

Angular View Vector​

AngularViewVector​

US​

1-n​

(0054,0100)​

Time Slice Vector​

TimeSliceVector​

US​

1-n​

(0054,0101)​ Number of Time Slices​

NumberOfTimeSlices​

US​

1​

(0054,0200)​

Start Angle​

StartAngle​

DS​

1​

(0054,0202)​ Type of Detector Motion​

TypeOfDetectorMotion​

CS​

1​

(0054,0210)​

Trigger Vector​

TriggerVector​

IS​

1-n​

(0054,0211)​ Number of Triggers in Phase​

NumberOfTriggersInPhase​

US​

1​

(0054,0220)​

View Code Sequence​

ViewCodeSequence​

SQ​

1​

(0054,0222)​ View Modifier Code Sequence​

ViewModifierCodeSequence​

SQ​

1​

(0054,0300)​

Radionuclide Code Sequence​

RadionuclideCodeSequence​

SQ​

1​

(0054,0302)​

Administration Route Code​

AdministrationRouteCode​

SQ​

1​

Sequence​

Sequence​

(0054,0304)​

Radiopharmaceutical Code​

RadiopharmaceuticalCode​

SQ​

1​

Sequence​

Sequence​

(0054,0306)​

Calibration Data Sequence​

CalibrationDataSequence​

SQ​

1​

(0054,0308)​

Energy Window Number​

EnergyWindowNumber​

US​

1​

(0054,0400)​

Image ID​

ImageID​

SH​

1​

(0054,0410)​ PatientOrientationCodeSequence​PatientOrientationCodeSequence​

SQ​

1​

(0054,0412)​ Patient Orientation Modifier Code​PatientOrientationModifierCode​

SQ​

1​

Sequence​

Sequence​

(0054,0414)​ Patient Gantry Relationship Code​PatientGantryRelationshipCode​

SQ​

1​

Sequence​

Sequence​

(0054,0500)​

Slice Progression Direction​

SliceProgressionDirection​

CS​

1​

(0054,0501)​

Scan Progression Direction​

ScanProgressionDirection​

CS​

1​

(0054,1000)​

Series Type​

SeriesType​

CS​

2​

(0054,1001)​

Units​

Units​

CS​

1​

(0054,1002)​

Counts Source​

CountsSource​

CS​

1​

(0054,1004)​

Reprojection Method​

ReprojectionMethod​

CS​

1​

(0054,1006)​

SUV Type​

SUVType​

CS​

1​

(0054,1100)​

Randoms Correction Method​

RandomsCorrectionMethod​

CS​

1​

(0054,1101)​

Attenuation Correction Method​

AttenuationCorrectionMethod​

LO​

1​

(0054,1102)​

Decay Correction​

DecayCorrection​

CS​

1​

(0054,1103)​

Reconstruction Method​

ReconstructionMethod​

LO​

1​

(0054,1104)​ Detector Lines of Response Used​DetectorLinesOfResponseUsed​

LO​

1​

(0054,1105)​

Scatter Correction Method​

ScatterCorrectionMethod​

LO​

1​

Page 104​

DICOM PS3.6 2020a - Data Dictionary​

Tag​

Name​

Keyword​

VR​

VM​

(0054,1200)​

Axial Acceptance​

AxialAcceptance​

DS​

1​

(0054,1201)​

Axial Mash​

AxialMash​

IS​

2​

(0054,1202)​

Transverse Mash​

TransverseMash​

IS​

1​

(0054,1203)​

Detector Element Size​

DetectorElementSize​

DS​

2​

(0054,1210)​

Coincidence Window Width​

CoincidenceWindowWidth​

DS​

1​

(0054,1220)​

Secondary Counts Type​

SecondaryCountsType​

CS​

1-n​

(0054,1300)​

Frame Reference Time​

FrameReferenceTime​

DS​

1​

(0054,1310)​

Primary (Prompts) Counts​

PrimaryPromptsCounts​

IS​

1​

Accumulated​

Accumulated​

(0054,1311)​

Secondary Counts Accumulated​

SecondaryCountsAccumulated​

IS​

1-n​

(0054,1320)​

Slice Sensitivity Factor​

SliceSensitivityFactor​

DS​

1​

(0054,1321)​

Decay Factor​

DecayFactor​

DS​

1​

(0054,1322)​

Dose Calibration Factor​

DoseCalibrationFactor​

DS​

1​

(0054,1323)​

Scatter Fraction Factor​

ScatterFractionFactor​

DS​

1​

(0054,1324)​

Dead Time Factor​

DeadTimeFactor​

DS​

1​

(0054,1330)​

Image Index​

ImageIndex​

US​

1​

(0054,1400)​

Counts Included​

CountsIncluded​

CS​

1-n​

RET​

(2007)​

(0054,1401)​

Dead Time Correction Flag​

DeadTimeCorrectionFlag​

CS​

1​

RET​

(2007)​

(0060,3000)​

Histogram Sequence​

HistogramSequence​

SQ​

1​

(0060,3002)​

Histogram Number of Bins​

HistogramNumberOfBins​

US​

1​

(0060,3004)​

Histogram First Bin Value​

HistogramFirstBinValue​

US or SS​

1​

(0060,3006)​

Histogram Last Bin Value​

HistogramLastBinValue​

US or SS​

1​

(0060,3008)​

Histogram Bin Width​

HistogramBinWidth​

US​

1​

(0060,3010)​

Histogram Explanation​

HistogramExplanation​

LO​

1​

(0060,3020)​

Histogram Data​

HistogramData​

UL​

1-n​

(0062,0001)​

Segmentation Type​

SegmentationType​

CS​

1​

(0062,0002)​

Segment Sequence​

SegmentSequence​

SQ​

1​

(0062,0003)​

Segmented Property Category​

SegmentedPropertyCategoryCode​

SQ​

1​

Code Sequence​

Sequence​

(0062,0004)​

Segment Number​

SegmentNumber​

US​

1​

(0062,0005)​

Segment Label​

SegmentLabel​

LO​

1​

(0062,0006)​

Segment Description​

SegmentDescription​

ST​

1​

(0062,0007)​

Segmentation Algorithm​

SegmentationAlgorithm​

SQ​

1​

Identification Sequence​

IdentificationSequence​

(0062,0008)​

Segment Algorithm Type​

SegmentAlgorithmType​

CS​

1​

(0062,0009)​

Segment Algorithm Name​

SegmentAlgorithmName​

LO​

1​

(0062,000A)​

Segment Identification Sequence​SegmentIdentificationSequence​

SQ​

1​

(0062,000B)​

Referenced Segment Number​

ReferencedSegmentNumber​

US​

1-n​

(0062,000C)​

Recommended Display Grayscale​RecommendedDisplayGrayscale​

US​

1​

Value​

Value​

(0062,000D)​

Recommended Display CIELab​

RecommendedDisplayCIELab​

US​

3​

Value​

Value​

DICOM PS3.6 2020a - Data Dictionary​

Page 105​

Tag​

Name​

Keyword​

VR​

VM​

(0062,000E)​

Maximum Fractional Value​

MaximumFractionalValue​

US​

1​

(0062,000F)​

Segmented Property Type Code​

SegmentedPropertyTypeCode​

SQ​

1​

Sequence​

Sequence​

(0062,0010)​

Segmentation Fractional Type​

SegmentationFractionalType​

CS​

1​

(0062,0011)​

SegmentedPropertyTypeModifier​SegmentedPropertyTypeModifier​

SQ​

1​

Code Sequence​

CodeSequence​

(0062,0012)​

Used Segments Sequence​

UsedSegmentsSequence​

SQ​

1​

(0062,0013)​

Segments Overlap​

SegmentsOverlap​

CS​

1​

(0062,0020)​

Tracking ID​

TrackingID​

UT​

1​

(0062,0021)​

Tracking UID​

TrackingUID​

UI​

1​

(0064,0002)​

DeformableRegistrationSequence​DeformableRegistrationSequence​

SQ​

1​

(0064,0003)​

Source Frame of Reference UID​ SourceFrameOfReferenceUID​

UI​

1​

(0064,0005)​

Deformable Registration Grid​

DeformableRegistrationGrid​

SQ​

1​

Sequence​

Sequence​

(0064,0007)​

Grid Dimensions​

GridDimensions​

UL​

3​

(0064,0008)​

Grid Resolution​

GridResolution​

FD​

3​

(0064,0009)​

Vector Grid Data​

VectorGridData​

OF​

1​

(0064,000F)​ PreDeformationMatrixRegistration​PreDeformationMatrixRegistration​

SQ​

1​

Sequence​

Sequence​

(0064,0010)​

Post Deformation Matrix​

PostDeformationMatrixRegistration​

SQ​

1​

Registration Sequence​

Sequence​

(0066,0001)​

Number of Surfaces​

NumberOfSurfaces​

UL​

1​

(0066,0002)​

Surface Sequence​

SurfaceSequence​

SQ​

1​

(0066,0003)​

Surface Number​

SurfaceNumber​

UL​

1​

(0066,0004)​

Surface Comments​

SurfaceComments​

LT​

1​

(0066,0009)​

Surface Processing​

SurfaceProcessing​

CS​

1​

(0066,000A)​

Surface Processing Ratio​

SurfaceProcessingRatio​

FL​

1​

(0066,000B)​

Surface Processing Description​

SurfaceProcessingDescription​

LO​

1​

(0066,000C)​

Recommended Presentation​

RecommendedPresentation​

FL​

1​

Opacity​

Opacity​

(0066,000D)​

Recommended Presentation Type​RecommendedPresentationType​

CS​

1​

(0066,000E)​

Finite Volume​

FiniteVolume​

CS​

1​

(0066,0010)​

Manifold​

Manifold​

CS​

1​

(0066,0011)​

Surface Points Sequence​

SurfacePointsSequence​

SQ​

1​

(0066,0012)​

Surface Points Normals Sequence​SurfacePointsNormalsSequence​

SQ​

1​

(0066,0013)​

SurfaceMeshPrimitivesSequence​SurfaceMeshPrimitivesSequence​

SQ​

1​

(0066,0015)​

Number of Surface Points​

NumberOfSurfacePoints​

UL​

1​

(0066,0016)​

Point Coordinates Data​

PointCoordinatesData​

OF​

1​

(0066,0017)​

Point Position Accuracy​

PointPositionAccuracy​

FL​

3​

(0066,0018)​

Mean Point Distance​

MeanPointDistance​

FL​

1​

(0066,0019)​

Maximum Point Distance​

MaximumPointDistance​

FL​

1​

(0066,001A)​ Points Bounding Box Coordinates​PointsBoundingBoxCoordinates​

FL​

6​

(0066,001B)​

Axis of Rotation​

AxisOfRotation​

FL​

3​
