DICOM PS3.6 2020a - Data Dictionary​

Page 81​

Tag​

Name​

Keyword​

VR​

VM​

(0028,7003)​

Display Subsystem ID​

DisplaySubsystemID​

US​

1​

(0028,7004)​

Display Subsystem Name​

DisplaySubsystemName​

SH​

1​

(0028,7005)​

Display Subsystem Description​

DisplaySubsystemDescription​

LO​

1​

(0028,7006)​

System Status​

SystemStatus​

CS​

1​

(0028,7007)​

System Status Comment​

SystemStatusComment​

LO​

1​

(0028,7008)​

Target Luminance Characteristics​TargetLuminanceCharacteristics​

SQ​

1​

Sequence​

Sequence​

(0028,7009)​

Luminance Characteristics ID​

LuminanceCharacteristicsID​

US​

1​

(0028,700A)​

Display Subsystem Configuration​DisplaySubsystemConfiguration​

SQ​

1​

Sequence​

Sequence​

(0028,700B)​

Configuration ID​

ConfigurationID​

US​

1​

(0028,700C)​

Configuration Name​

ConfigurationName​

SH​

1​

(0028,700D)​

Configuration Description​

ConfigurationDescription​

LO​

1​

(0028,700E)​

Referenced Target Luminance​

ReferencedTargetLuminance​

US​

1​

Characteristics ID​

CharacteristicsID​

(0028,700F)​

QA Results Sequence​

QAResultsSequence​

SQ​

1​

(0028,7010)​

Display Subsystem QA Results​

DisplaySubsystemQAResults​

SQ​

1​

Sequence​

Sequence​

(0028,7011)​

ConfigurationQAResultsSequence​ConfigurationQAResultsSequence​

SQ​

1​

(0028,7012)​

MeasurementEquipmentSequence​MeasurementEquipmentSequence​

SQ​

1​

(0028,7013)​

Measurement Functions​

MeasurementFunctions​

CS​

1-n​

(0028,7014)​

Measurement Equipment Type​

MeasurementEquipmentType​

CS​

1​

(0028,7015)​

VisualEvaluationResultSequence​VisualEvaluationResultSequence​

SQ​

1​

(0028,7016)​

Display Calibration Result​

DisplayCalibrationResultSequence​

SQ​

1​

Sequence​

(0028,7017)​

DDL Value​

DDLValue​

US​

1​

(0028,7018)​

CIExy White Point​

CIExyWhitePoint​

FL​

2​

(0028,7019)​

Display Function Type​

DisplayFunctionType​

CS​

1​

(0028,701A)​

Gamma Value​

GammaValue​

FL​

1​

(0028,701B)​

Number of Luminance Points​

NumberOfLuminancePoints​

US​

1​

(0028,701C)​

Luminance Response Sequence​

LuminanceResponseSequence​

SQ​

1​

(0028,701D)​

Target Minimum Luminance​

TargetMinimumLuminance​

FL​

1​

(0028,701E)​

Target Maximum Luminance​

TargetMaximumLuminance​

FL​

1​

(0028,701F)​

Luminance Value​

LuminanceValue​

FL​

1​

(0028,7020)​

Luminance Response Description​LuminanceResponseDescription​

LO​

1​

(0028,7021)​

White Point Flag​

WhitePointFlag​

CS​

1​

(0028,7022)​

Display Device Type Code​

DisplayDeviceTypeCodeSequence​

SQ​

1​

Sequence​

(0028,7023)​

Display Subsystem Sequence​

DisplaySubsystemSequence​

SQ​

1​

(0028,7024)​

Luminance Result Sequence​

LuminanceResultSequence​

SQ​

1​

(0028,7025)​

Ambient Light Value Source​

AmbientLightValueSource​

CS​

1​

(0028,7026)​

Measured Characteristics​

MeasuredCharacteristics​

CS​

1-n​

(0028,7027)​

Luminance Uniformity Result​

LuminanceUniformityResult​

SQ​

1​

Sequence​

Sequence​

Page 82​

DICOM PS3.6 2020a - Data Dictionary​

Tag​

Name​

Keyword​

VR​

VM​

(0028,7028)​

Visual Evaluation Test Sequence​VisualEvaluationTestSequence​

SQ​

1​

(0028,7029)​

Test Result​

TestResult​

CS​

1​

(0028,702A)​

Test Result Comment​

TestResultComment​

LO​

1​

(0028,702B)​

Test Image Validation​

TestImageValidation​

CS​

1​

(0028,702C)​

Test Pattern Code Sequence​

TestPatternCodeSequence​

SQ​

1​

(0028,702D)​

Measurement Pattern Code​

MeasurementPatternCode​

SQ​

1​

Sequence​

Sequence​

(0028,702E)​ Visual Evaluation Method Code​

VisualEvaluationMethodCode​

SQ​

1​

Sequence​

Sequence​

(0028,7FE0)​

Pixel Data Provider URL​

PixelDataProviderURL​

UR​

1​

(0028,9001)​

Data Point Rows​

DataPointRows​

UL​

1​

(0028,9002)​

Data Point Columns​

DataPointColumns​

UL​

1​

(0028,9003)​

Signal Domain Columns​

SignalDomainColumns​

CS​

1​

(0028,9099)​

Largest Monochrome Pixel Value​LargestMonochromePixelValue​

US​

1​

RET​

(2003)​

(0028,9108)​

Data Representation​

DataRepresentation​

CS​

1​

(0028,9110)​

Pixel Measures Sequence​

PixelMeasuresSequence​

SQ​

1​

(0028,9132)​

Frame VOI LUT Sequence​

FrameVOILUTSequence​

SQ​

1​

(0028,9145)​

Pixel Value Transformation​

PixelValueTransformation​

SQ​

1​

Sequence​

Sequence​

(0028,9235)​

Signal Domain Rows​

SignalDomainRows​

CS​

1​

(0028,9411)​

Display Filter Percentage​

DisplayFilterPercentage​

FL​

1​

(0028,9415)​

Frame Pixel Shift Sequence​

FramePixelShiftSequence​

SQ​

1​

(0028,9416)​

Subtraction Item ID​

SubtractionItemID​

US​

1​

(0028,9422)​

Pixel Intensity Relationship LUT​

PixelIntensityRelationshipLUT​

SQ​

1​

Sequence​

Sequence​

(0028,9443)​

Frame Pixel Data Properties​

FramePixelDataProperties​

SQ​

1​

Sequence​

Sequence​

(0028,9444)​

Geometrical Properties​

GeometricalProperties​

CS​

1​

(0028,9445)​

Geometric Maximum Distortion​

GeometricMaximumDistortion​

FL​

1​

(0028,9446)​

Image Processing Applied​

ImageProcessingApplied​

CS​

1-n​

(0028,9454)​

Mask Selection Mode​

MaskSelectionMode​

CS​

1​

(0028,9474)​

LUT Function​

LUTFunction​

CS​

1​

(0028,9478)​

Mask Visibility Percentage​

MaskVisibilityPercentage​

FL​

1​

(0028,9501)​

Pixel Shift Sequence​

PixelShiftSequence​

SQ​

1​

(0028,9502)​

Region Pixel Shift Sequence​

RegionPixelShiftSequence​

SQ​

1​

(0028,9503)​

Vertices of the Region​

VerticesOfTheRegion​

SS​

2-2n​

(0028,9505)​

Multi-framePresentationSequence​MultiFramePresentationSequence​

SQ​

1​

(0028,9506)​

Pixel Shift Frame Range​

PixelShiftFrameRange​

US​

2-2n​

(0028,9507)​

LUT Frame Range​

LUTFrameRange​

US​

2-2n​

(0028,9520)​

ImagetoEquipmentMappingMatrix​ImageToEquipmentMappingMatrix​

DS​

16​

(0028,9537)​

Equipment Coordinate System​

EquipmentCoordinateSystem​

CS​

1​

Identification​

Identification​

DICOM PS3.6 2020a - Data Dictionary​

Page 83​

Tag​

Name​

Keyword​

VR​

VM​

(0032,000A)​

Study Status ID​

StudyStatusID​

CS​

1​

RET​

(2004)​

(0032,000C)​

Study Priority ID​

StudyPriorityID​

CS​

1​

RET​

(2004)​

(0032,0012)​

Study ID Issuer​

StudyIDIssuer​

LO​

1​

RET​

(2004)​

(0032,0032)​

Study Verified Date​

StudyVerifiedDate​

DA​

1​

RET​

(2004)​

(0032,0033)​

Study Verified Time​

StudyVerifiedTime​

TM​

1​

RET​

(2004)​

(0032,0034)​

Study Read Date​

StudyReadDate​

DA​

1​

RET​

(2004)​

(0032,0035)​

Study Read Time​

StudyReadTime​

TM​

1​

RET​

(2004)​

(0032,1000)​

Scheduled Study Start Date​

ScheduledStudyStartDate​

DA​

1​

RET​

(2004)​

(0032,1001)​

Scheduled Study Start Time​

ScheduledStudyStartTime​

TM​

1​

RET​

(2004)​

(0032,1010)​

Scheduled Study Stop Date​

ScheduledStudyStopDate​

DA​

1​

RET​

(2004)​

(0032,1011)​

Scheduled Study Stop Time​

ScheduledStudyStopTime​

TM​

1​

RET​

(2004)​

(0032,1020)​

Scheduled Study Location​

ScheduledStudyLocation​

LO​

1​

RET​

(2004)​

(0032,1021)​

Scheduled Study Location AE Title​ScheduledStudyLocationAETitle​

AE​

1-n​

RET​

(2004)​

(0032,1030)​

Reason for Study​

ReasonForStudy​

LO​

1​

RET​

(2004)​

(0032,1031)​

RequestingPhysicianIdentification​RequestingPhysicianIdentification​

SQ​

1​

Sequence​

Sequence​

(0032,1032)​

Requesting Physician​

RequestingPhysician​

PN​

1​

(0032,1033)​

Requesting Service​

RequestingService​

LO​

1​

(0032,1034)​

Requesting Service Code​

RequestingServiceCodeSequence​

SQ​

1​

Sequence​

(0032,1040)​

Study Arrival Date​

StudyArrivalDate​

DA​

1​

RET​

(2004)​

(0032,1041)​

Study Arrival Time​

StudyArrivalTime​

TM​

1​

RET​

(2004)​

(0032,1050)​

Study Completion Date​

StudyCompletionDate​

DA​

1​

RET​

(2004)​

(0032,1051)​

Study Completion Time​

StudyCompletionTime​

TM​

1​

RET​

(2004)​

(0032,1055)​

Study Component Status ID​

StudyComponentStatusID​

CS​

1​

RET​

(2004)​

(0032,1060)​

Requested Procedure Description​RequestedProcedureDescription​

LO​

1​

(0032,1064)​

Requested Procedure Code​

RequestedProcedureCode​

SQ​

1​

Sequence​

Sequence​

(0032,1066)​

Reason for Visit​

ReasonForVisit​

UT​

1​

Page 84​

DICOM PS3.6 2020a - Data Dictionary​

Tag​

Name​

Keyword​

VR​

VM​

(0032,1067)​

Reason for Visit Code Sequence​

ReasonForVisitCodeSequence​

SQ​

1​

(0032,1070)​

Requested Contrast Agent​

RequestedContrastAgent​

LO​

1​

(0032,4000)​

Study Comments​

StudyComments​

LT​

1​

RET​

(2007)​

(0034,0001)​

Flow Identifier Sequence​

FlowIdentifierSequence​

SQ​

1​

(0034,0002)​

Flow Identifier​

FlowIdentifier​

OB​

1​

(0034,0003)​

Flow Transfer Syntax UID​

FlowTransferSyntaxUID​

UI​

1​

(0034,0004)​

Flow RTP Sampling Rate​

FlowRTPSamplingRate​

UL​

1​

(0034,0005)​

Source Identifier​

SourceIdentifier​

OB​

1​

(0034,0007)​

Frame Origin Timestamp​

FrameOriginTimestamp​

OB​

1​

(0034,0008)​

Includes Imaging Subject​

IncludesImagingSubject​

CS​

1​

(0034,0009)​

FrameUsefulnessGroupSequence​FrameUsefulnessGroupSequence​

SQ​

1​

(0034,000A)​

Real-Time Bulk Data Flow​

RealTimeBulkDataFlowSequence​

SQ​

1​

Sequence​

(0034,000B)​

Camera Position Group Sequence​CameraPositionGroupSequence​

SQ​

1​

(0034,000C)​

Includes Information​

IncludesInformation​

CS​

1​

(0034,000D)​

Time of Frame Group Sequence​ TimeOfFrameGroupSequence​

SQ​

1​

(0038,0004)​

ReferencedPatientAliasSequence​ReferencedPatientAliasSequence​

SQ​

1​

(0038,0008)​

Visit Status ID​

VisitStatusID​

CS​

1​

(0038,0010)​

Admission ID​

AdmissionID​

LO​

1​

(0038,0011)​

Issuer of Admission ID​

IssuerOfAdmissionID​

LO​

1​

RET​

(2008)​

(0038,0014)​

Issuer of Admission ID Sequence​IssuerOfAdmissionIDSequence​

SQ​

1​

(0038,0016)​

Route of Admissions​

RouteOfAdmissions​

LO​

1​

(0038,001A)​

Scheduled Admission Date​

ScheduledAdmissionDate​

DA​

1​

RET​

(2004)​

(0038,001B)​

Scheduled Admission Time​

ScheduledAdmissionTime​

TM​

1​

RET​

(2004)​

(0038,001C)​

Scheduled Discharge Date​

ScheduledDischargeDate​

DA​

1​

RET​

(2004)​

(0038,001D)​

Scheduled Discharge Time​

ScheduledDischargeTime​

TM​

1​

RET​

(2004)​

(0038,001E)​

Scheduled Patient Institution​

ScheduledPatientInstitution​

LO​

1​

RET​

Residence​

Residence​

(2004)​

(0038,0020)​

Admitting Date​

AdmittingDate​

DA​

1​

(0038,0021)​

Admitting Time​

AdmittingTime​

TM​

1​

(0038,0030)​

Discharge Date​

DischargeDate​

DA​

1​

RET​

(2004)​

(0038,0032)​

Discharge Time​

DischargeTime​

TM​

1​

RET​

(2004)​

(0038,0040)​

Discharge Diagnosis Description​ DischargeDiagnosisDescription​

LO​

1​

RET​

(2004)​

(0038,0044)​

Discharge Diagnosis Code​

DischargeDiagnosisCode​

SQ​

1​

RET​

Sequence​

Sequence​

(2004)​

(0038,0050)​

Special Needs​

SpecialNeeds​

LO​

1​

DICOM PS3.6 2020a - Data Dictionary​

Page 85​

Tag​

Name​

Keyword​

VR​

VM​

(0038,0060)​

Service Episode ID​

ServiceEpisodeID​

LO​

1​

(0038,0061)​

Issuer of Service Episode ID​

IssuerOfServiceEpisodeID​

LO​

1​

RET​

(2008)​

(0038,0062)​

Service Episode Description​

ServiceEpisodeDescription​

LO​

1​

(0038,0064)​

Issuer of Service Episode ID​

IssuerOfServiceEpisodeID​

SQ​

1​

Sequence​

Sequence​

(0038,0100)​

Pertinent Documents Sequence​

PertinentDocumentsSequence​

SQ​

1​

(0038,0101)​

Pertinent Resources Sequence​

PertinentResourcesSequence​

SQ​

1​

(0038,0102)​

Resource Description​

ResourceDescription​

LO​

1​

(0038,0300)​

Current Patient Location​

CurrentPatientLocation​

LO​

1​

(0038,0400)​

Patient's Institution Residence​

PatientInstitutionResidence​

LO​

1​

(0038,0500)​

Patient State​

PatientState​

LO​

1​

(0038,0502)​

Patient Clinical Trial Participation​PatientClinicalTrialParticipation​

SQ​

1​

Sequence​

Sequence​

(0038,4000)​

Visit Comments​

VisitComments​

LT​

1​

(003A,0004)​

Waveform Originality​

WaveformOriginality​

CS​

1​

(003A,0005)​

Number of Waveform Channels​

NumberOfWaveformChannels​

US​

1​

(003A,0010)​

Number of Waveform Samples​

NumberOfWaveformSamples​

UL​

1​

(003A,001A)​

Sampling Frequency​

SamplingFrequency​

DS​

1​

(003A,0020)​

Multiplex Group Label​

MultiplexGroupLabel​

SH​

1​

(003A,0200)​

Channel Definition Sequence​

ChannelDefinitionSequence​

SQ​

1​

(003A,0202)​

Waveform Channel Number​

WaveformChannelNumber​

IS​

1​

(003A,0203)​

Channel Label​

ChannelLabel​

SH​

1​

(003A,0205)​

Channel Status​

ChannelStatus​

CS​

1-n​

(003A,0208)​

Channel Source Sequence​

ChannelSourceSequence​

SQ​

1​

(003A,0209)​

Channel Source Modifiers​

ChannelSourceModifiersSequence​

SQ​

1​

Sequence​

(003A,020A)​

Source Waveform Sequence​

SourceWaveformSequence​

SQ​

1​

(003A,020C)​

Channel Derivation Description​

ChannelDerivationDescription​

LO​

1​

(003A,0210)​

Channel Sensitivity​

ChannelSensitivity​

DS​

1​

(003A,0211)​

ChannelSensitivityUnitsSequence​ChannelSensitivityUnitsSequence​

SQ​

1​

(003A,0212)​

Channel Sensitivity Correction​

ChannelSensitivityCorrection​

DS​

1​

Factor​

Factor​

(003A,0213)​

Channel Baseline​

ChannelBaseline​

DS​

1​

(003A,0214)​

Channel Time Skew​

ChannelTimeSkew​

DS​

1​

(003A,0215)​

Channel Sample Skew​

ChannelSampleSkew​

DS​

1​

(003A,0218)​

Channel Offset​

ChannelOffset​

DS​

1​

(003A,021A)​

Waveform Bits Stored​

WaveformBitsStored​

US​

1​

(003A,0220)​

Filter Low Frequency​

FilterLowFrequency​

DS​

1​

(003A,0221)​

Filter High Frequency​

FilterHighFrequency​

DS​

1​

(003A,0222)​

Notch Filter Frequency​

NotchFilterFrequency​

DS​

1​

(003A,0223)​

Notch Filter Bandwidth​

NotchFilterBandwidth​

DS​

1​

(003A,0230)​

Waveform Data Display Scale​

WaveformDataDisplayScale​

FL​

1​
