Page 56​

DICOM PS3.6 2020a - Data Dictionary​

Tag​

Name​

Keyword​

VR​

VM​

(0018,9370)​

X-Ray Detector Index​

XRayDetectorIndex​

US​

1​

(0018,9371)​

X-Ray Detector ID​

XRayDetectorID​

UC​

1​

(0018,9372)​

Multi-energy Detector Type​

MultienergyDetectorType​

CS​

1​

(0018,9373)​

X-Ray Detector Label​

XRayDetectorLabel​

ST​

1​

(0018,9374)​

Nominal Max Energy​

NominalMaxEnergy​

DS​

1​

(0018,9375)​

Nominal Min Energy​

NominalMinEnergy​

DS​

1​

(0018,9376)​

Referenced X-Ray Detector Index​ReferencedXRayDetectorIndex​

US​

1-n​

(0018,9377)​

Referenced X-Ray Source Index​ ReferencedXRaySourceIndex​

US​

1-n​

(0018,9378)​

Referenced Path Index​

ReferencedPathIndex​

US​

1-n​

(0018,9379)​

Multi-energy CT Path Sequence​

MultienergyCTPathSequence​

SQ​

1​

(0018,937A)​

Multi-energy CT Path Index​

MultienergyCTPathIndex​

US​

1​

(0018,937B)​

Multi-energyAcquisitionDescription​MultienergyAcquisitionDescription​

UT​

1​

(0018,937C)​

Monoenergetic Energy Equivalent​MonoenergeticEnergyEquivalent​

FD​

1​

(0018,937D)​

Material Code Sequence​

MaterialCodeSequence​

SQ​

1​

(0018,937E)​

Decomposition Method​

DecompositionMethod​

CS​

1​

(0018,937F)​

Decomposition Description​

DecompositionDescription​

UT​

1​

(0018,9380)​

Decomposition Algorithm​

DecompositionAlgorithm​

SQ​

1​

Identification Sequence​

IdentificationSequence​

(0018,9381)​

Decomposition Material Sequence​DecompositionMaterialSequence​

SQ​

1​

(0018,9382)​

Material Attenuation Sequence​

MaterialAttenuationSequence​

SQ​

1​

(0018,9383)​

Photon Energy​

PhotonEnergy​

DS​

1​

(0018,9384)​

X-RayMassAttenuationCoefficient​XRayMassAttenuationCoefficient​

DS​

1​

(0018,9401)​

Projection Pixel Calibration​

ProjectionPixelCalibration​

SQ​

1​

Sequence​

Sequence​

(0018,9402)​

Distance Source to Isocenter​

DistanceSourceToIsocenter​

FL​

1​

(0018,9403)​

Distance Object to Table Top​

DistanceObjectToTableTop​

FL​

1​

(0018,9404)​

Object Pixel Spacing in Center of​ObjectPixelSpacingInCenterOf​

FL​

2​

Beam​

Beam​

(0018,9405)​

Positioner Position Sequence​

PositionerPositionSequence​

SQ​

1​

(0018,9406)​

Table Position Sequence​

TablePositionSequence​

SQ​

1​

(0018,9407)​

Collimator Shape Sequence​

CollimatorShapeSequence​

SQ​

1​

(0018,9410)​

Planes in Acquisition​

PlanesInAcquisition​

CS​

1​

(0018,9412)​

XA/XRF Frame Characteristics​

XAXRFFrameCharacteristics​

SQ​

1​

Sequence​

Sequence​

(0018,9417)​

Frame Acquisition Sequence​

FrameAcquisitionSequence​

SQ​

1​

(0018,9420)​

X-Ray Receptor Type​

XRayReceptorType​

CS​

1​

(0018,9423)​

Acquisition Protocol Name​

AcquisitionProtocolName​

LO​

1​

(0018,9424)​

Acquisition Protocol Description​

AcquisitionProtocolDescription​

LT​

1​

(0018,9425)​

Contrast/Bolus Ingredient Opaque​ContrastBolusIngredientOpaque​

CS​

1​

(0018,9426)​

Distance Receptor Plane to​

DistanceReceptorPlaneToDetector​

FL​

1​

Detector Housing​

Housing​

(0018,9427)​

Intensifier Active Shape​

IntensifierActiveShape​

CS​

1​

(0018,9428)​

Intensifier Active Dimension(s)​

IntensifierActiveDimensions​

FL​

1-2​

DICOM PS3.6 2020a - Data Dictionary​

Page 57​

Tag​

Name​

Keyword​

VR​

VM​

(0018,9429)​

Physical Detector Size​

PhysicalDetectorSize​

FL​

2​

(0018,9430)​

Position of Isocenter Projection​

PositionOfIsocenterProjection​

FL​

2​

(0018,9432)​

Field of View Sequence​

FieldOfViewSequence​

SQ​

1​

(0018,9433)​

Field of View Description​

FieldOfViewDescription​

LO​

1​

(0018,9434)​

ExposureControlSensingRegions​ExposureControlSensingRegions​

SQ​

1​

Sequence​

Sequence​

(0018,9435)​

Exposure Control Sensing Region​ExposureControlSensingRegion​

CS​

1​

Shape​

Shape​

(0018,9436)​

Exposure Control Sensing Region​ExposureControlSensingRegion​

SS​

1​

Left Vertical Edge​

LeftVerticalEdge​

(0018,9437)​

Exposure Control Sensing Region​ExposureControlSensingRegion​

SS​

1​

Right Vertical Edge​

RightVerticalEdge​

(0018,9438)​

Exposure Control Sensing Region​ExposureControlSensingRegion​

SS​

1​

Upper Horizontal Edge​

UpperHorizontalEdge​

(0018,9439)​

Exposure Control Sensing Region​ExposureControlSensingRegion​

SS​

1​

Lower Horizontal Edge​

LowerHorizontalEdge​

(0018,9440)​

CenterofCircularExposureControl​CenterOfCircularExposureControl​

SS​

2​

Sensing Region​

SensingRegion​

(0018,9441)​

RadiusofCircularExposureControl​RadiusOfCircularExposureControl​

US​

1​

Sensing Region​

SensingRegion​

(0018,9442)​

VerticesofthePolygonalExposure​VerticesOfThePolygonalExposure​

SS​

2-n​

Control Sensing Region​

ControlSensingRegion​

(0018,9445)​

RET​

(2004) -​

See Note​

3​

(0018,9447)​

Column Angulation (Patient)​

ColumnAngulationPatient​

FL​

1​

(0018,9449)​

Beam Angle​

BeamAngle​

FL​

1​

(0018,9451)​

Frame Detector Parameters​

FrameDetectorParameters​

SQ​

1​

Sequence​

Sequence​

(0018,9452)​

Calculated Anatomy Thickness​

CalculatedAnatomyThickness​

FL​

1​

(0018,9455)​

Calibration Sequence​

CalibrationSequence​

SQ​

1​

(0018,9456)​

Object Thickness Sequence​

ObjectThicknessSequence​

SQ​

1​

(0018,9457)​

Plane Identification​

PlaneIdentification​

CS​

1​

(0018,9461)​

Field of View Dimension(s) in Float​FieldOfViewDimensionsInFloat​

FL​

1-2​

(0018,9462)​

Isocenter Reference System​

IsocenterReferenceSystem​

SQ​

1​

Sequence​

Sequence​

(0018,9463)​

Positioner Isocenter Primary Angle​PositionerIsocenterPrimaryAngle​

FL​

1​

(0018,9464)​

Positioner Isocenter Secondary​

PositionerIsocenterSecondary​

FL​

1​

Angle​

Angle​

(0018,9465)​

Positioner Isocenter Detector​

PositionerIsocenterDetector​

FL​

1​

Rotation Angle​

RotationAngle​

(0018,9466)​

Table X Position to Isocenter​

TableXPositionToIsocenter​

FL​

1​

(0018,9467)​

Table Y Position to Isocenter​

TableYPositionToIsocenter​

FL​

1​

(0018,9468)​

Table Z Position to Isocenter​

TableZPositionToIsocenter​

FL​

1​

(0018,9469)​

Table Horizontal Rotation Angle​

TableHorizontalRotationAngle​

FL​

1​

Page 58​

DICOM PS3.6 2020a - Data Dictionary​

Tag​

Name​

Keyword​

VR​

VM​

(0018,9470)​

Table Head Tilt Angle​

TableHeadTiltAngle​

FL​

1​

(0018,9471)​

Table Cradle Tilt Angle​

TableCradleTiltAngle​

FL​

1​

(0018,9472)​

Frame Display Shutter Sequence​FrameDisplayShutterSequence​

SQ​

1​

(0018,9473)​

AcquiredImageAreaDoseProduct​AcquiredImageAreaDoseProduct​

FL​

1​

(0018,9474)​

C-arm Positioner Tabletop​

CArmPositionerTabletop​

CS​

1​

Relationship​

Relationship​

(0018,9476)​

X-Ray Geometry Sequence​

XRayGeometrySequence​

SQ​

1​

(0018,9477)​

Irradiation Event Identification​

IrradiationEventIdentification​

SQ​

1​

Sequence​

Sequence​

(0018,9504)​

X-Ray 3D Frame Type Sequence​XRay3DFrameTypeSequence​

SQ​

1​

(0018,9506)​

Contributing Sources Sequence​

ContributingSourcesSequence​

SQ​

1​

(0018,9507)​

X-Ray 3D Acquisition Sequence​

XRay3DAcquisitionSequence​

SQ​

1​

(0018,9508)​

Primary Positioner Scan Arc​

PrimaryPositionerScanArc​

FL​

1​

(0018,9509)​

Secondary Positioner Scan Arc​

SecondaryPositionerScanArc​

FL​

1​

(0018,9510)​

PrimaryPositionerScanStartAngle​PrimaryPositionerScanStartAngle​

FL​

1​

(0018,9511)​

Secondary Positioner Scan Start​ SecondaryPositionerScanStart​

FL​

1​

Angle​

Angle​

(0018,9514)​

Primary Positioner Increment​

PrimaryPositionerIncrement​

FL​

1​

(0018,9515)​

Secondary Positioner Increment​

SecondaryPositionerIncrement​

FL​

1​

(0018,9516)​

Start Acquisition DateTime​

StartAcquisitionDateTime​

DT​

1​

(0018,9517)​

End Acquisition DateTime​

EndAcquisitionDateTime​

DT​

1​

(0018,9518)​

Primary Positioner Increment Sign​PrimaryPositionerIncrementSign​

SS​

1​

(0018,9519)​

Secondary Positioner Increment​

SecondaryPositionerIncrement​

SS​

1​

Sign​

Sign​

(0018,9524)​

Application Name​

ApplicationName​

LO​

1​

(0018,9525)​

Application Version​

ApplicationVersion​

LO​

1​

(0018,9526)​

Application Manufacturer​

ApplicationManufacturer​

LO​

1​

(0018,9527)​

Algorithm Type​

AlgorithmType​

CS​

1​

(0018,9528)​

Algorithm Description​

AlgorithmDescription​

LO​

1​

(0018,9530)​

X-Ray3DReconstructionSequence​XRay3DReconstructionSequence​

SQ​

1​

(0018,9531)​

Reconstruction Description​

ReconstructionDescription​

LO​

1​

(0018,9538)​

Per Projection Acquisition​

PerProjectionAcquisitionSequence​

SQ​

1​

Sequence​

(0018,9541)​

Detector Position Sequence​

DetectorPositionSequence​

SQ​

1​

(0018,9542)​

X-Ray Acquisition Dose Sequence​XRayAcquisitionDoseSequence​

SQ​

1​

(0018,9543)​

X-Ray Source Isocenter Primary​ XRaySourceIsocenterPrimary​

FD​

1​

Angle​

Angle​

(0018,9544)​

X-RaySourceIsocenterSecondary​XRaySourceIsocenterSecondary​

FD​

1​

Angle​

Angle​

(0018,9545)​

Breast Support Isocenter Primary​BreastSupportIsocenterPrimary​

FD​

1​

Angle​

Angle​

(0018,9546)​

Breast Support Isocenter​

BreastSupportIsocenterSecondary​

FD​

1​

Secondary Angle​

Angle​

DICOM PS3.6 2020a - Data Dictionary​

Page 59​

Tag​

Name​

Keyword​

VR​

VM​

(0018,9547)​

Breast Support X Position to​

BreastSupportXPositionTo​

FD​

1​

Isocenter​

Isocenter​

(0018,9548)​

Breast Support Y Position to​

BreastSupportYPositionTo​

FD​

1​

Isocenter​

Isocenter​

(0018,9549)​

Breast Support Z Position to​

BreastSupportZPositionTo​

FD​

1​

Isocenter​

Isocenter​

(0018,9550)​

Detector Isocenter Primary Angle​DetectorIsocenterPrimaryAngle​

FD​

1​

(0018,9551)​

DetectorIsocenterSecondaryAngle​DetectorIsocenterSecondaryAngle​

FD​

1​

(0018,9552)​

Detector X Position to Isocenter​

DetectorXPositionToIsocenter​

FD​

1​

(0018,9553)​

Detector Y Position to Isocenter​

DetectorYPositionToIsocenter​

FD​

1​

(0018,9554)​

Detector Z Position to Isocenter​

DetectorZPositionToIsocenter​

FD​

1​

(0018,9555)​

X-Ray Grid Sequence​

XRayGridSequence​

SQ​

1​

(0018,9556)​

X-Ray Filter Sequence​

XRayFilterSequence​

SQ​

1​

(0018,9557)​

DetectorActiveAreaTLHCPosition​DetectorActiveAreaTLHCPosition​

FD​

3​

(0018,9558)​

Detector Active Area Orientation​ DetectorActiveAreaOrientation​

FD​

6​

(0018,9559)​

Positioner Primary Angle Direction​PositionerPrimaryAngleDirection​

CS​

1​

(0018,9601)​

Diffusion b-matrix Sequence​

DiffusionBMatrixSequence​

SQ​

1​

(0018,9602)​

Diffusion b-value XX​

DiffusionBValueXX​

FD​

1​

(0018,9603)​

Diffusion b-value XY​

DiffusionBValueXY​

FD​

1​

(0018,9604)​

Diffusion b-value XZ​

DiffusionBValueXZ​

FD​

1​

(0018,9605)​

Diffusion b-value YY​

DiffusionBValueYY​

FD​

1​

(0018,9606)​

Diffusion b-value YZ​

DiffusionBValueYZ​

FD​

1​

(0018,9607)​

Diffusion b-value ZZ​

DiffusionBValueZZ​

FD​

1​

(0018,9621)​

Functional MR Sequence​

FunctionalMRSequence​

SQ​

1​

(0018,9622)​

Functional Settling Phase Frames​FunctionalSettlingPhaseFrames​

CS​

1​

Present​

Present​

(0018,9623)​

Functional Sync Pulse​

FunctionalSyncPulse​

DT​

1​

(0018,9624)​

Settling Phase Frame​

SettlingPhaseFrame​

CS​

1​

(0018,9701)​

Decay Correction DateTime​

DecayCorrectionDateTime​

DT​

1​

(0018,9715)​

Start Density Threshold​

StartDensityThreshold​

FD​

1​

(0018,9716)​

Start Relative Density Difference​

StartRelativeDensityDifference​

FD​

1​

Threshold​

Threshold​

(0018,9717)​

Start Cardiac Trigger Count​

StartCardiacTriggerCount​

FD​

1​

Threshold​

Threshold​

(0018,9718)​

Start Respiratory Trigger Count​

StartRespiratoryTriggerCount​

FD​

1​

Threshold​

Threshold​

(0018,9719)​

Termination Counts Threshold​

TerminationCountsThreshold​

FD​

1​

(0018,9720)​

Termination Density Threshold​

TerminationDensityThreshold​

FD​

1​

(0018,9721)​

Termination Relative Density​

TerminationRelativeDensity​

FD​

1​

Threshold​

Threshold​

(0018,9722)​

Termination Time Threshold​

TerminationTimeThreshold​

FD​

1​

(0018,9723)​

Termination Cardiac Trigger Count​TerminationCardiacTriggerCount​

FD​

1​

Threshold​

Threshold​

Page 60​

DICOM PS3.6 2020a - Data Dictionary​

Tag​

Name​

Keyword​

VR​

VM​

(0018,9724)​

Termination Respiratory Trigger​

TerminationRespiratoryTrigger​

FD​

1​

Count Threshold​

CountThreshold​

(0018,9725)​

Detector Geometry​

DetectorGeometry​

CS​

1​

(0018,9726)​

Transverse Detector Separation​

TransverseDetectorSeparation​

FD​

1​

(0018,9727)​

Axial Detector Dimension​

AxialDetectorDimension​

FD​

1​

(0018,9729)​

Radiopharmaceutical Agent​

RadiopharmaceuticalAgentNumber​

US​

1​

Number​

(0018,9732)​ PET Frame Acquisition Sequence​PETFrameAcquisitionSequence​

SQ​

1​

(0018,9733)​ PET Detector Motion Details​

PETDetectorMotionDetails​

SQ​

1​

Sequence​

Sequence​

(0018,9734)​ PET Table Dynamics Sequence​

PETTableDynamicsSequence​

SQ​

1​

(0018,9735)​

PET Position Sequence​

PETPositionSequence​

SQ​

1​

(0018,9736)​ PET Frame Correction Factors​

PETFrameCorrectionFactors​

SQ​

1​

Sequence​

Sequence​

(0018,9737)​

Radiopharmaceutical Usage​

RadiopharmaceuticalUsage​

SQ​

1​

Sequence​

Sequence​

(0018,9738)​

Attenuation Correction Source​

AttenuationCorrectionSource​

CS​

1​

(0018,9739)​

Number of Iterations​

NumberOfIterations​

US​

1​

(0018,9740)​

Number of Subsets​

NumberOfSubsets​

US​

1​

(0018,9749)​

PET Reconstruction Sequence​

PETReconstructionSequence​

SQ​

1​

(0018,9751)​ PET Frame Type Sequence​

PETFrameTypeSequence​

SQ​

1​

(0018,9755)​ Time of Flight Information Used​

TimeOfFlightInformationUsed​

CS​

1​

(0018,9756)​

Reconstruction Type​

ReconstructionType​

CS​

1​

(0018,9758)​

Decay Corrected​

DecayCorrected​

CS​

1​

(0018,9759)​

Attenuation Corrected​

AttenuationCorrected​

CS​

1​

(0018,9760)​

Scatter Corrected​

ScatterCorrected​

CS​

1​

(0018,9761)​

Dead Time Corrected​

DeadTimeCorrected​

CS​

1​

(0018,9762)​

Gantry Motion Corrected​

GantryMotionCorrected​

CS​

1​

(0018,9763)​

Patient Motion Corrected​

PatientMotionCorrected​

CS​

1​

(0018,9764)​

Count Loss Normalization​

CountLossNormalizationCorrected​

CS​

1​

Corrected​

(0018,9765)​

Randoms Corrected​

RandomsCorrected​

CS​

1​

(0018,9766)​

Non-uniform Radial Sampling​

NonUniformRadialSampling​

CS​

1​

Corrected​

Corrected​

(0018,9767)​

Sensitivity Calibrated​

SensitivityCalibrated​

CS​

1​

(0018,9768)​

Detector Normalization Correction​DetectorNormalizationCorrection​

CS​

1​

(0018,9769)​

Iterative Reconstruction Method​

IterativeReconstructionMethod​

CS​

1​

(0018,9770)​

Attenuation Correction Temporal​

AttenuationCorrectionTemporal​

CS​

1​

Relationship​

Relationship​

(0018,9771)​

Patient Physiological State​

PatientPhysiologicalState​

SQ​

1​

Sequence​

Sequence​

(0018,9772)​ Patient Physiological State Code​

PatientPhysiologicalStateCode​

SQ​

1​

Sequence​

Sequence​

(0018,9801)​

Depth(s) of Focus​

DepthsOfFocus​

FD​

1-n​
