DISCRETE SEMICONDUCTORS

BGD702MI

Hybrid CATV amplifier module

Product speciﬁcation			1996 Jul 15
File under Discrete Semiconductors, SC16

Philips Semiconductors			Product speciﬁcation


	Hybrid CATV ampliﬁer module		BGD702MI


FEATURES		PINNING - SOT115J2
∙	Excellent linearity
∙	Excellent linearity	PIN	DESCRIPTION
∙	Extremely low noise
∙	Extremely low noise	1	output
		1	output
∙	Silicon nitride passivation	2	common
∙	Rugged construction	3	common
∙	Gold metallization ensures excellent reliability	5	+VB
∙	Mirrored image pinning of the BGD702.	7	common
		8	common
APPLICATIONS		9	input

∙CATV systems operating in the 40 to 750 MHz frequency range.

handbook, halfpage

DESCRIPTION

Hybrid amplifier module in a SOT115J2 package operating with a voltage supply of 24 V (DC).

1 2 3	5	7 8 9
Side view		MSA319 - 1

Fig.1 Simplified outline.

QUICK REFERENCE DATA

SYMBOL	PARAMETER	CONDITIONS	MIN.	MAX.	UNIT

Gp	power gain	f = 50 MHz	18	19	dB
		f = 750 MHz	18.5	−	dB

Itot	total current consumption (DC)	VB = 24 V	−	435	mA

LIMITING VALUES

In accordance with the Absolute Maximum Rating System (IEC 134).

SYMBOL	PARAMETER	MIN.	MAX.	UNIT

VB	supply voltage	−	25	V
Vi	RF input voltage	−	60	dBmV
Tstg	storage temperature	−40	+100	°C
Tmb	operating mounting base temperature	−20	+100	°C

1996 Jul 15

Philips Semiconductors				Product speciﬁcation

Hybrid CATV ampliﬁer module				BGD702MI

CHARACTERISTICS
Bandwidth 40 to 750 MHz; VB = 24 V; Tmb = 35 °C; ZS = ZL = 75 Ω.

SYMBOL	PARAMETER	CONDITIONS	MIN.	MAX.	UNIT

Gp	power gain	f = 50 MHz	18	19	dB
		f = 750 MHz	18.5	−	dB

SL	slope cable equivalent	f = 40 to 750 MHz	0.2	2	dB

FL	ﬂatness of frequency response	f = 40 to 750 MHz	−	±0.5	dB

S11	input return losses	f = 40 to 80 MHz	20	−	dB
		f = 80 to 160 MHz	18.5	−	dB

		f = 160 to 320 MHz	17	−	dB

		f = 320 to 640 MHz	15.5	−	dB

		f = 640 to 750 MHz	14	−	dB

S22	output return losses	f = 40 to 80 MHz	20	−	dB
		f = 80 to 160 MHz	18.5	−	dB

		f = 160 to 320 MHz	17	−	dB

		f = 320 to 640 MHz	15.5	−	dB

		f = 640 to 750 MHz	14	−	dB

S21	phase response	f = 50 MHz	−45	+45	deg
CTB	composite triple beat	110 channels ﬂat;	−	−58	dB
		Vo = 44 dBmV;
		measured at 745.25 MHz

Xmod	cross modulation	110 channels ﬂat;	−	−62	dB
		Vo = 44 dBmV;
		measured at 55.25 MHz

CSO	composite second order distortion	110 channels ﬂat;	−	−58	dB
		Vo = 44 dBmV;
		measured at 746.5 MHz

d2	second order distortion	note 1	−	−68	dB
Vo	output voltage	dim = −60 dB; note 2	61	−	dBmV
F	noise ﬁgure	f = 50 MHz	−	5.5	dB

		f = 750 MHz	−	9	dB

Itot	total current consumption (DC)	note 3	−	435	mA

Notes

1.fp = 55.25 MHz; Vp = 44 dBmV; fq = 691.25 MHz; Vq = 44 dBmV; measured at fp + fq = 746.5 MHz.

2.Measured according to DIN45004B:

fp = 740.25 MHz; Vp = Vo;

fq = 747.25 MHz; Vq = Vo −6 dB; fr = 749.25 MHz; Vr = Vo −6 dB;

measured at fp + fq − fr = 738.25 MHz.

3.The module normally operates at VB = 24 V, but is able to withstand supply transients up to 30 V.

1996 Jul 15

Philips Semiconductors				Product speciﬁcation

Hybrid CATV ampliﬁer module				BGD702MI

CHARACTERISTICS
Bandwidth 40 to 600 MHz; VB = 24 V; Tmb = 35 °C; ZS = ZL = 75 Ω.

SYMBOL	PARAMETER	CONDITIONS	MIN.	MAX.	UNIT

Gp	power gain	f = 50 MHz	18	19	dB
		f = 600 MHz	18.5	−	dB

SL	slope cable equivalent	f = 40 to 600 MHz	0.2	2	dB

FL	ﬂatness of frequency response	f = 40 to 600 MHz	−	±0.3	dB

S11	input return losses	f = 40 to 80 MHz	20	−	dB
		f = 80 to 160 MHz	18.5	−	dB

		f = 160 to 320 MHz	17	−	dB

		f = 320 to 600 MHz	16	−	dB

S22	output return losses	f = 40 to 80 MHz	20	−	dB
		f = 80 to 160 MHz	18.5	−	dB

		f = 160 to 320 MHz	17	−	dB

		f = 320 to 600 MHz	16	−	dB

S21	phase response	f = 50 MHz	−45	+45	deg
CTB	composite triple beat	85 channels ﬂat;	−	−65	dB
		Vo = 44 dBmV;
		measured at 595.25 MHz

Xmod	cross modulation	85 channels ﬂat;	−	−65	dB
		Vo = 44 dBmV;
		measured at 55.25 MHz

CSO	composite second order distortion	85 channels ﬂat;	−	−60	dB
		Vo = 44 dBmV;
		measured at 596.5 MHz

d2	second order distortion	note 1	−	−70	dB
Vo	output voltage	dim = −60 dB; note 2	64	−	dBmV
F	noise ﬁgure	f = 50 MHz	−	5.5	dB

		f = 600 MHz	−	8	dB

Itot	total current consumption (DC)	note 3	−	435	mA

Notes

1.fp = 55.25 MHz; Vp = 44 dBmV; fq = 541.25 MHz; Vq = 44 dBmV; measured at fp + fq = 596.5 MHz.

2.Measured according to DIN45004B:

fp = 590.25 MHz; Vp = Vo;

fq = 597.25 MHz; Vq = Vo −6 dB; fr = 599.25 MHz; Vr = Vo −6 dB;

measured at fp + fq − fr = 588.25 MHz.

3.The module normally operates at VB = 24 V, but is able to withstand supply transients up to 30 V.

1996 Jul 15

Philips Semiconductors				Product speciﬁcation

Hybrid CATV ampliﬁer module				BGD702MI

CHARACTERISTICS
Bandwidth 40 to 550 MHz; VB = 24 V; Tmb = 35 °C; ZS = ZL = 75 Ω.

SYMBOL	PARAMETER	CONDITIONS	MIN.	MAX.	UNIT

Gp	power gain	f = 50 MHz	18	19	dB
		f = 550 MHz	18.5	−	dB

SL	slope cable equivalent	f = 40 to 550 MHz	0.2	2	dB

FL	ﬂatness of frequency response	f = 40 to 550 MHz	−	±0.3	dB

S11	input return losses	f = 40 to 80 MHz	20	−	dB
		f = 80 to 160 MHz	18.5	−	dB

		f = 160 to 320 MHz	17	−	dB

		f = 320 to 550 MHz	16	−	dB

S22	output return losses	f = 40 to 80 MHz	20	−	dB
		f = 80 to 160 MHz	18.5	−	dB

		f = 160 to 320 MHz	17	−	dB

		f = 320 to 550 MHz	16	−	dB

S21	phase response	f = 50 MHz	−45	+45	deg
CTB	composite triple beat	77 channels ﬂat;	−	−67	dB
		Vo = 44 dBmV;
		measured at 547.25 MHz

Xmod	cross modulation	77 channels ﬂat;	−	−67	dB
		Vo = 44 dBmV;
		measured at 55.25 MHz

CSO	composite second order distortion	77 channels ﬂat;	−	−62	dB
		Vo = 44 dBmV;
		measured at 548.5 MHz

d2	second order distortion	note 1	−	−72	dB
Vo	output voltage	dim = −60 dB; note 2	64.5	−	dBmV
F	noise ﬁgure	f = 50 MHz	−	5.5	dB

		f = 550 MHz	−	7.5	dB

Itot	total current consumption (DC)	note 3	−	435	mA

Notes

1.fp = 55.25 MHz; Vp = 44 dBmV; fq = 493.25 MHz; Vq = 44 dBmV; measured at fp + fq = 548.5 MHz.

2.Measured according to DIN45004B:

fp = 540.25 MHz; Vp = Vo;

fq = 547.25 MHz; Vq = Vo −6 dB; fr = 549.25 MHz; Vr = Vo −6 dB;

measured at fp + fq − fr = 538.25 MHz.

3.The module normally operates at VB = 24 V, but is able to withstand supply transients up to 30 V.

1996 Jul 15
