MOTOROLA

SEMICONDUCTOR TECHNICAL DATA

Order this document by MOC8080/D

GlobalOptoisolator

6-Pin DIP Optoisolator Darlington Output

The MOC8080 device consists of a gallium arsenide infrared emitting diode optically coupled to a monolithic silicon photodarlington detector. They are designed for use in applications requiring high gain at specified input currents.

•High Output Collector Current (IC)

•Low, Stable Leakage Current at Elevated Temperature

•To order devices that are tested and marked per VDE 0884 requirements, the suffix ºVº must be included at end of part number. VDE 0884 is a test option.

Applications

•Appliances, Measuring Instruments

•General Purpose Switching Circuits

•Programmable Controllers

•Portable Electronics

•Interfacing and coupling systems of different potentials and impedances

•Solid State Relays

MAXIMUM RATINGS (TA = 25°C unless otherwise noted)

Rating	Symbol	Value	Unit

INPUT LED

Reverse Voltage	VR	6	Volts
Forward Current Ð Continuous	IF	60	mA
LED Power Dissipation @ TA = 25°C	PD	120	mW
with Negligible Power in Output Detector
Derate above 25°C		1.41	mW/°C

OUTPUT DETECTOR

Collector±Emitter Voltage	VCEO	55	Volts
Emitter±Collector Voltage	VECO	5	Volts
Collector±Base Voltage	VCBO	55	Volts
Collector Current Ð Continuous	IC	150	mA
Detector Power Dissipation @ TA = 25°C	PD	150	mW
with Negligible Power in Input LED
Derate above 25°C		1.76	mW/°C

TOTAL DEVICE

Isolation Surge Voltage(1)	V	7500	Vac(pk)
(Peak ac Voltage, 60 Hz, 1 sec Duration)	ISO
(Peak ac Voltage, 60 Hz, 1 sec Duration)

Total Device Power Dissipation @ TA = 25°C	PD	250	mW
Derate above 25°C		2.94	mW/°C

Ambient Operating Temperature Range(2)	T	± 55 to +100	°C
	A
Storage Temperature Range(2)	T	± 55 to +150	°C
	stg
Soldering Temperature (10 sec, 1/16″ from case)	TL	260	°C

1.Isolation surge voltage is an internal device dielectric breakdown rating.

For this test, Pins 1 and 2 are common, and Pins 4, 5 and 6 are common.

2.Refer to Quality and Reliability Section in Opto Data Book for information on test conditions.

Preferred devices are Motorola recommended choices for future use and best overall value.

GlobalOptoisolator is a trademark of Motorola, Inc.

MOC8080

[CTR = 500% Min]

Motorola Preferred Device

STYLE 1 PLASTIC

6

1

STANDARD THRU HOLE

CASE 730A±04

	SCHEMATIC
1	6
2	5
	5
3	4
	4

PIN 1. LED ANODE

2.LED CATHODE

3.N.C.

4.EMITTER

5.COLLECTOR

6.BASE

REV 1

Motorola Optoelectronics Device Data

Motorola, Inc. 1995

MOC8080

ELECTRICAL CHARACTERISTICS (T					= 25°C unless otherwise noted)(1)
			A
	Characteristic						Symbol	Min	Typ(1)	Max	Unit
INPUT LED

Forward Voltage (IF = 10 mA)						TA = 25°C	VF	0.8	1.15	1.5	V
						TA = ±55°C		0.9	1.3	1.7
						TA = 100°C		0.7	1.05	1.4
Reverse Leakage Current (VR = 3 V)							IR	Ð	Ð	100	μA
Capacitance (V = 0 V, f = 1 MHz)							C	Ð	18	Ð	pF

OUTPUT DETECTOR

Collector±Emitter Dark Current (VCE = 10 V)						TA = 25°C	ICEO	Ð	5	100	nA
						TA = 100°C		Ð	5	100	μA
Collector±Base Dark Current (VCB = 10 V)						TA = 25°C	ICBO	Ð	1	20	nA
						TA = 100°C		Ð	100	Ð
Collector±Emitter Breakdown Voltage (IC = 1 mA)							V(BR)CEO	55	80	Ð	V
Collector±Base Breakdown Voltage (IC = 100 μA)							V(BR)CBO	55	100	Ð	V
Emitter±Collector Breakdown Voltage (IE = 100 μA)							V(BR)ECO	5	7	Ð	V
DC Current Gain (IC = 5 mA, VCE = 5 V) (Typical)							hFE	Ð	16 k	Ð	Ð
Collector±Emitter Capacitance (f = 1 MHz, VCE = 5 V)							CCE	Ð	3.9	Ð	pF
Collector±Base Capacitance (f = 1 MHz, VCB = 5 V)							CCB	Ð	6.3	Ð	pF
Emitter±Base Capacitance (f = 1 MHz, VEB = 5 V)							CEB	Ð	3.8	Ð	pF
COUPLED

Output Collector Current (I		= 10 mA, V	CE	= 5 V)			I (CTR)(2)	50 (500)	117 (1117)	Ð	mA (%)
	F		CE				C
Collector±Emitter Saturation Voltage (IC = 1 mA, IF = 1 mA)							VCE(sat)	Ð	0.6	1	V
Turn±On Time							ton	Ð	3.5	Ð	μs
Turn±Off Time		VCC = 10 V, RL = 100 Ω, IF = 5 mA(3)					toff	Ð	95	Ð
Rise Time		VCC = 10 V, RL = 100 Ω, IF = 5 mA(3)					tr	Ð	1	Ð
Rise Time							tr	Ð	1	Ð
Fall Time							tf	Ð	2	Ð
Isolation Voltage (f = 60 Hz, t = 1 sec)(4)							VISO	7500	Ð	Ð	Vac(pk)
Isolation Resistance (V = 500 V)(4)							RISO	1011	Ð	Ð	Ω
Isolation Capacitance (V = 0 V, f = 1 MHz)(4)							CISO	Ð	0.2	2	pF

1.Always design to the specified minimum/maximum electrical limits (where applicable).

2.Current Transfer Ratio (CTR) = IC/IF x 100%.

3.For test circuit setup and waveforms, refer to Figure 11.

4.For this test, Pins 1 and 2 are common, and Pins 4, 5 and 6 are common.

	(VOLTS)	2
	(VOLTS)	1.8
	VOLTAGE	1.8
	VOLTAGE	1.6
	FORWARD,	1.6
	FORWARD,	1.2
		1.4
	F
	V
		1

1

		TYPICAL CHARACTERISTICS
			(NORMALIZED)	10
				10
PULSE ONLY				NORMALIZED TO: IF = 10 mA
PULSE OR DC				NORMALIZED TO: IF = 10 mA
					TA = 25°C
			CURRENT	1
25 C			CURRENT
25 C			COLLECTOR	TA = ±55°C THRU
TA = ±55°C				0.1
TA = ±55°C				+25°C
°	100	1000	OUTPUT	+70°C	1	2	5	10	20	50
10	100	1000	OUTPUT	0.5	1	2	5	10	20	50
100°C				+100°C
100°C				0.01
				0.01
I , LED FORWARD CURRENT (mA)			,		I , LED INPUT CURRENT (mA)
I , LED FORWARD CURRENT (mA)			C		I , LED INPUT CURRENT (mA)
F			I		F

Figure 1. LED Forward Voltage versus Forward Current

Figure 2. Output Current versus Input Current

2	Motorola Optoelectronics Device Data

	140
(mA)	120
(mA)						IF = 10 mA
CURRENT	100
	80						5 mA

,COLLECTOR
	60
	40
							2 mA
C	20						2 mA
C
I

	0						1 mA
	0	1	2	3	4	5	6	7	8	9	10
	0	1	2	3	4	5	6	7	8	9	10
			VCE, COLLECTOR±EMITTER VOLTAGE (VOLTS)

Figure 3. Collector Current versus

Collector±Emitter Voltage

(NORMALIZED)	1.3
(NORMALIZED)
VOLTAGE		NORMALIZED	TO	TA = 25°C
	1.2	NORMALIZED	TO	TA = 25°C


COLLECTOR±EMITTER,	1.1
	1.1
	1
	1
	0.9
	0.9
	0.8
	0.8
	0.7
	0.7

CE	±60	±40	±20	0	20	40	60	80	100
V			TA, AMBIENT TEMPERATURE (°C)
			TA, AMBIENT TEMPERATURE (°C)

Figure 5. Collector±Emitter Voltage versus Ambient Temperature

MOC8080

(NORMALIZED)	10
	7
	7
	5
	5

CURRENT	1				NORMALIZED	TO		TA = 25°C
COLLECTOR	2
	2
	0.7





	0.5
	0.5
, OUTPUT	0.2



	0.1
	0.1	±60 ±40 ±20		0	20 40 60		80 100
C			TA, AMBIENT TEMPERATURE (°C)
I			TA, AMBIENT TEMPERATURE (°C)

Figure 4. Output Current versus Ambient Temperature

(NORMALIZED)	105
CURRENT	104	NORMALIZED TO: VCE = 10 V
		NORMALIZED TO: TA = 25°C
	103
DARK	103
DARK
COLLECTOR±EMITTER	102		VCE = 55 V
	10		30 V
	10
			10 V
	1	20	40	60	80	100
	0
,	0
CEO			TA, AMBIENT TEMPERATURE (°C)
I

Figure 6. Collector±Emitter Dark Current versus Ambient Temperature







									V	CC = 10 V
100					R	L = 1000
100








10						100
10





						10
1
1	0.1	0.2	0.5	1		2	5	10	20		50	100
1000
s) ( μ
TIMEt,

IF, LED INPUT CURRENT (mA)

Figure 7. Turn±On Switching Times

(Typical Values)

1000
				RL = 1000



100					100
(μs)



TIMEt,
TIMEt,					10
10					10









1								V	CC = 10 V


0.1	0.2	0.5	1		2	5	10	20		50	100
			IF, LED INPUT CURRENT (mA)

Figure 8. Turn±Off Switching Times

(Typical Values)

Motorola Optoelectronics Device Data

3

MOC8080

IC, TYPICAL COLLECTOR CURRENT (mA)

14
14	I	F	= 0								IB =	0.7 μA
12	I		= 0								IB =	0.7 μA


												0.6 μA
												0.5 μA
10
10
8

												0.4 μA
6												0.4 μA

												0.3 μA
												0.3 μA
4
4												0.2 μA
												0.2 μA
2												0.1 μA
0
0
0			2	4	6	8	10	12	14	16	18		20

VCE, COLLECTOR±EMITTER VOLTAGE (VOLTS)

	20
	18
	16						f = 1 MHz
	14		CCB				f = 1 MHz
(pF)	14		CCB
(pF)	12
C, CAPACITANCE	10
	8
	6
	4
	2								CEB	CCE
									CEB	CCE
	0.05	0.1	0.2	0.5	1	2	5	10	20	50
				VE, VOLTAGE (VOLTS)

Figure 9. DC Current Gain (Detector Only)		Figure 10. Detector Capacitances versus Voltage
	TEST CIRCUIT	WAVEFORMS
	VCC = 10 V		INPUT PULSE
	VCC = 10 V
IF = 5 mA	RL = 100 Ω	10%
		10%
INPUT	OUTPUT	90%	OUTPUT PULSE
	OUTPUT

		tr	tf
		ton	toff

Figure 11. Switching Time Test Circuit and Waveforms

4	Motorola Optoelectronics Device Data

MOC8080

PACKAGE DIMENSIONS

	±A±
			NOTES:
6	4		1. DIMENSIONING AND TOLERANCING PER ANSI
6	4		Y14.5M, 1982.
			Y14.5M, 1982.
	±B±		2. CONTROLLING DIMENSION: INCH.
1	3		3. DIMENSION L TO CENTER OF LEAD WHEN
1	3		FORMED PARALLEL.
				INCHES		MILLIMETERS
F 4 PL	C	L	DIM	MIN	MAX	MIN	MAX
	C		A	0.320	0.350	8.13	8.89
	N		A	0.320	0.350	8.13	8.89
	N		B	0.240	0.260	6.10	6.60
			B	0.240	0.260	6.10	6.60
			C	0.115	0.200	2.93	5.08
			D	0.016	0.020	0.41	0.50
			E	0.040	0.070	1.02	1.77
±T±	K		F	0.010	0.014	0.25	0.36
±T±			G	0.100 BSC		2.54 BSC
SEATING			G	0.100 BSC		2.54 BSC
SEATING			J	0.008	0.012	0.21	0.30
PLANE	G	J 6 PL	K	0.100	0.150	2.54	3.81
		J 6 PL	K	0.100	0.150	2.54	3.81
		0.13 (0.005) M T B M A M	L	0.300 BSC		7.62 BSC
	M		L	0.300 BSC		7.62 BSC
E 6 PL	M		M	0	15	0	15
E 6 PL	D 6 PL		N	0.015	0.100	0.38	2.54
			N	0.015	0.100	0.38	2.54

	0.13 (0.005) M T A M	B M			STYLE 1:
					STYLE 1:
					PIN 1.	ANODE
					2.	CATHODE
					3.	NC
					4.	EMITTER
					5.	COLLECTOR
					6.	BASE

CASE 730A±04

ISSUE G

±A±

6	4
	±B± S
1	3
F 4 PL	H	L
	H
	C
	G	J	±T±
	G	J	SEATING
E 6 PL		K 6 PL	PLANE
E 6 PL		K 6 PL
	D 6 PL	0.13 (0.005) M	T B M A M
	0.13 (0.005) M T A M	B M

NOTES:

1.DIMENSIONING AND TOLERANCING PER ANSI Y14.5M, 1982.

2.CONTROLLING DIMENSION: INCH.

	INCHES		MILLIMETERS
DIM	MIN	MAX	MIN	MAX
A	0.320	0.350	8.13	8.89
B	0.240	0.260	6.10	6.60
C	0.115	0.200	2.93	5.08
D	0.016	0.020	0.41	0.50
E	0.040	0.070	1.02	1.77
F	0.010	0.014	0.25	0.36
G	0.100 BSC		2.54 BSC
H	0.020	0.025	0.51	0.63
J	0.008	0.012	0.20	0.30
K	0.006	0.035	0.16	0.88
L	0.320 BSC		8.13 BSC
S	0.332	0.390	8.43	9.90

*Consult factory for leadform

option availability

CASE 730C±04

ISSUE D

Motorola Optoelectronics Device Data

5
